Pressure Control Modular
Yuken
Yuken — 03 Series Reducing Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-03-REDUCING
03 Series Modular Valves — Reducing. Sandwich/stack mounting. Detailed specifications by inquiry.
15 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MRP-03-*-70 | Reducing modular valve 03, P-line | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: RFQ | ||
| MRA-03-*-70 | Reducing modular valve 03, A-line | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: RFQ | ||
| MRB-03-*-70 | Reducing modular valve 03, B-line | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: RFQ | ||
| MRP-03-A-70 | Reducing modular valve, P-line, range A | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: A: max 3.5 MPa | Max Pressure: 35 MPa | Max Flow: 80 L/min | ||
| MRP-03-B-70 | Reducing modular valve, P-line, range B | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: B: 1–7 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MRP-03-C-70 | Reducing modular valve, P-line, range C | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MRP-03-H-70 | Reducing modular valve, P-line, range H | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: H: 7–31.5 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MRA-03-A-70 | Reducing modular valve, A-line, range A | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: A: max 3.5 MPa | Max Pressure: 35 MPa | Max Flow: 80 L/min | ||
| MRA-03-B-70 | Reducing modular valve, A-line, range B | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: B: 1–7 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MRA-03-C-70 | Reducing modular valve, A-line, range C | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MRA-03-H-70 | Reducing modular valve, A-line, range H | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: H: 7–31.5 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MRB-03-A-70 | Reducing modular valve, B-line, range A | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: A: max 3.5 MPa | Max Pressure: 35 MPa | Max Flow: 80 L/min | ||
| MRB-03-B-70 | Reducing modular valve, B-line, range B | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: B: 1–7 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MRB-03-C-70 | Reducing modular valve, B-line, range C | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MRB-03-H-70 | Reducing modular valve, B-line, range H | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: H: 7–31.5 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min |
