Yuken — 01 Series Two-Pressure Reducing Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-01-REDUCING2P
01 Series Modular Valves — Two-Pressure Reducing. Sandwich/stack mounting. Detailed specifications by inquiry.
2 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MRDP-01-B | Two-pressure reducing modular valve, P-line, range B (solenoid switched) | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Two-pressure reducing (P-line, solenoid) | Pressure Range: B: low 0.2–3.5 / high 0.5–7 MPa | Max Pressure: 14 MPa | Max Flow: 20 L/min | Coil (RFQ): AC A100/A200 · DC D24 · AC/DC R100/R200(opt) | Connection (RFQ): N: DIN · N1: DIN w/ lamp(opt) | Design: -10 | ||
| MRDP-01-C | Two-pressure reducing modular valve, P-line, range C (solenoid switched) | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Two-pressure reducing (P-line, solenoid) | Pressure Range: C: low 0.5–7 / high 0.5–14 MPa | Max Pressure: 14 MPa | Max Flow: 40 L/min | Coil (RFQ): AC A100/A200 · DC D24 · AC/DC R100/R200(opt) | Connection (RFQ): N: DIN · N1: DIN w/ lamp(opt) | Design: -10 |
