Pressure Control Modular
Yuken
Yuken — 03 Series Sequence / Counterbalance Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-03-SEQCOUNTER
03 Series Modular Valves — Sequence / Counterbalance. Sandwich/stack mounting. Detailed specifications by inquiry.
10 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MHP-03-*-20 | Sequence modular valve 03, P-line | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Sequence (P-line) | Pressure Range: RFQ | ||
| MHA-03-*-20 | Counterbalance modular valve 03, A-line | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (A-line) | Pressure Range: RFQ | ||
| MHB-03-*-20 | Counterbalance modular valve 03, B-line | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (B-line) | Pressure Range: RFQ | ||
| MHP-03-N-20 | Sequence modular valve, P-line, range N | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Sequence (P-line) | Pressure Range: N: max 1.8 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min | ||
| MHA-03-A-20 | Counterbalance modular valve, A-line, range A | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (A-line) | Pressure Range: A: 1.8–3.5 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70) | ||
| MHA-03-B-20 | Counterbalance modular valve, A-line, range B | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (A-line) | Pressure Range: B: 3.5–7 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70) | ||
| MHA-03-C-20 | Counterbalance modular valve, A-line, range C | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (A-line) | Pressure Range: C: 7–14 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70) | ||
| MHB-03-A-20 | Counterbalance modular valve, B-line, range A | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (B-line) | Pressure Range: A: 1.8–3.5 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70) | ||
| MHB-03-B-20 | Counterbalance modular valve, B-line, range B | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (B-line) | Pressure Range: B: 3.5–7 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70) | ||
| MHB-03-C-20 | Counterbalance modular valve, B-line, range C | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (B-line) | Pressure Range: C: 7–14 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70) |
