Gearheads
GGM
[GGM] — K10H□B Gearhead for □104 200W Geared Motors (□104mm, 1/3–1/200, No Decimal, Cap 40 N·m, ø18 Tapped Keyed Shaft)
Family ID: GGM-K10H-B
GGM K10H-B parallel-shaft gearhead for □104mm 200W GGM geared motors, sold separately. 24 gear ratios 1/3–1/200 (no decimal gearhead), ø18 (h7) keyed output shaft with M6×P1.0 tap hole, mounting 4-ø8.5 / ø120 B.C. / M8 P1.25, max permissible torque 40 N·m / 400 kgf·cm.
24 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| K10H3B | GGM K10H gearhead K10H3B — ratio 1/3, output 500/600 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/3 | Output Speed: 500 rpm @50Hz / 600 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H3.6B | GGM K10H gearhead K10H3.6B — ratio 1/3.6, output 416/500 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/3.6 | Output Speed: 416 rpm @50Hz / 500 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H5B | GGM K10H gearhead K10H5B — ratio 1/5, output 300/360 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/5 | Output Speed: 300 rpm @50Hz / 360 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H6B | GGM K10H gearhead K10H6B — ratio 1/6, output 250/300 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/6 | Output Speed: 250 rpm @50Hz / 300 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H7.5B | GGM K10H gearhead K10H7.5B — ratio 1/7.5, output 200/240 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/7.5 | Output Speed: 200 rpm @50Hz / 240 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H9B | GGM K10H gearhead K10H9B — ratio 1/9, output 166/200 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/9 | Output Speed: 166 rpm @50Hz / 200 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H10B | GGM K10H gearhead K10H10B — ratio 1/10, output 150/180 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/10 | Output Speed: 150 rpm @50Hz / 180 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H12.5B | GGM K10H gearhead K10H12.5B — ratio 1/12.5, output 120/144 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/12.5 | Output Speed: 120 rpm @50Hz / 144 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H15B | GGM K10H gearhead K10H15B — ratio 1/15, output 100/120 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/15 | Output Speed: 100 rpm @50Hz / 120 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H18B | GGM K10H gearhead K10H18B — ratio 1/18, output 83/100 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/18 | Output Speed: 83 rpm @50Hz / 100 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H20B | GGM K10H gearhead K10H20B — ratio 1/20, output 75/90 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/20 | Output Speed: 75 rpm @50Hz / 90 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H25B | GGM K10H gearhead K10H25B — ratio 1/25, output 60/72 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/25 | Output Speed: 60 rpm @50Hz / 72 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H30B | GGM K10H gearhead K10H30B — ratio 1/30, output 50/60 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/30 | Output Speed: 50 rpm @50Hz / 60 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H36B | GGM K10H gearhead K10H36B — ratio 1/36, output 41/50 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/36 | Output Speed: 41 rpm @50Hz / 50 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H40B | GGM K10H gearhead K10H40B — ratio 1/40, output 37/45 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/40 | Output Speed: 37 rpm @50Hz / 45 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H50B | GGM K10H gearhead K10H50B — ratio 1/50, output 30/36 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/50 | Output Speed: 30 rpm @50Hz / 36 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H60B | GGM K10H gearhead K10H60B — ratio 1/60, output 25/30 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/60 | Output Speed: 25 rpm @50Hz / 30 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H75B | GGM K10H gearhead K10H75B — ratio 1/75, output 20/24 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/75 | Output Speed: 20 rpm @50Hz / 24 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H90B | GGM K10H gearhead K10H90B — ratio 1/90, output 16/20 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/90 | Output Speed: 16 rpm @50Hz / 20 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H100B | GGM K10H gearhead K10H100B — ratio 1/100, output 15/18 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/100 | Output Speed: 15 rpm @50Hz / 18 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H120B | GGM K10H gearhead K10H120B — ratio 1/120, output 13/15 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/120 | Output Speed: 13 rpm @50Hz / 15 rpm @60Hz (4-pole AC input) [50Hz speed printed 13 — catalog anomaly, expected 12.5] | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H150B | GGM K10H gearhead K10H150B — ratio 1/150, output 10/12 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/150 | Output Speed: 10 rpm @50Hz / 12 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H180B | GGM K10H gearhead K10H180B — ratio 1/180, output 8.3/10 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/180 | Output Speed: 8.3 rpm @50Hz / 10 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm | ||
| K10H200B | GGM K10H gearhead K10H200B — ratio 1/200, output 7.5/9 rpm (50/60Hz), □104mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/200 | Output Speed: 7.5 rpm @50Hz / 9 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 40 N·m / 400 kgf·cm |
