![[GGM] — K9P□B Gearhead for □90 60–200W Geared Motors (□90mm, 1/3–1/200 + Decimal, Cap 20 N·m, ø15 Keyed Shaft)](https://img.prosourcemro.com/2026/06/0604-36-932x1024.png)
Gearheads
GGM
[GGM] — K9P□B Gearhead for □90 60–200W Geared Motors (□90mm, 1/3–1/200 + Decimal, Cap 20 N·m, ø15 Keyed Shaft)
Family ID: GGM-K9P-B
GGM K9P-B parallel-shaft gearhead for □90mm 60–200W GGM geared motors (induction, reversible, brake), sold separately. Standard □90mm mount (ø104 B.C., 4-ø6.5). 24 gear ratios 1/3–1/200 plus decimal gearhead K9P10BX, ø15 (h7) keyed output shaft, max permissible torque 20 N·m / 200 kgf·cm.
25 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| K9P3B | GGM K9P gearhead K9P3B — ratio 1/3, output 500/600 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/3 | Output Speed: 500 rpm @50Hz / 600 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P3.6B | GGM K9P gearhead K9P3.6B — ratio 1/3.6, output 416/500 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/3.6 | Output Speed: 416 rpm @50Hz / 500 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P5B | GGM K9P gearhead K9P5B — ratio 1/5, output 300/360 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/5 | Output Speed: 300 rpm @50Hz / 360 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P6B | GGM K9P gearhead K9P6B — ratio 1/6, output 250/300 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/6 | Output Speed: 250 rpm @50Hz / 300 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P7.5B | GGM K9P gearhead K9P7.5B — ratio 1/7.5, output 200/240 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/7.5 | Output Speed: 200 rpm @50Hz / 240 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P9B | GGM K9P gearhead K9P9B — ratio 1/9, output 166/200 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/9 | Output Speed: 166 rpm @50Hz / 200 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P10B | GGM K9P gearhead K9P10B — ratio 1/10, output 150/180 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/10 | Output Speed: 150 rpm @50Hz / 180 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P12.5B | GGM K9P gearhead K9P12.5B — ratio 1/12.5, output 120/144 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/12.5 | Output Speed: 120 rpm @50Hz / 144 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P15B | GGM K9P gearhead K9P15B — ratio 1/15, output 100/120 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/15 | Output Speed: 100 rpm @50Hz / 120 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P18B | GGM K9P gearhead K9P18B — ratio 1/18, output 83/100 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/18 | Output Speed: 83 rpm @50Hz / 100 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P20B | GGM K9P gearhead K9P20B — ratio 1/20, output 75/90 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/20 | Output Speed: 75 rpm @50Hz / 90 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P25B | GGM K9P gearhead K9P25B — ratio 1/25, output 60/72 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/25 | Output Speed: 60 rpm @50Hz / 72 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P30B | GGM K9P gearhead K9P30B — ratio 1/30, output 50/60 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/30 | Output Speed: 50 rpm @50Hz / 60 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P36B | GGM K9P gearhead K9P36B — ratio 1/36, output 41/50 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/36 | Output Speed: 41 rpm @50Hz / 50 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P40B | GGM K9P gearhead K9P40B — ratio 1/40, output 37/45 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/40 | Output Speed: 37 rpm @50Hz / 45 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P50B | GGM K9P gearhead K9P50B — ratio 1/50, output 30/36 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/50 | Output Speed: 30 rpm @50Hz / 36 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P60B | GGM K9P gearhead K9P60B — ratio 1/60, output 25/30 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/60 | Output Speed: 25 rpm @50Hz / 30 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P75B | GGM K9P gearhead K9P75B — ratio 1/75, output 20/24 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/75 | Output Speed: 20 rpm @50Hz / 24 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P90B | GGM K9P gearhead K9P90B — ratio 1/90, output 16/20 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/90 | Output Speed: 16 rpm @50Hz / 20 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P100B | GGM K9P gearhead K9P100B — ratio 1/100, output 15/18 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/100 | Output Speed: 15 rpm @50Hz / 18 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P120B | GGM K9P gearhead K9P120B — ratio 1/120, output 12.5/15 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/120 | Output Speed: 12.5 rpm @50Hz / 15 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P150B | GGM K9P gearhead K9P150B — ratio 1/150, output 10/12 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/150 | Output Speed: 10 rpm @50Hz / 12 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P180B | GGM K9P gearhead K9P180B — ratio 1/180, output 8.3/10 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/180 | Output Speed: 8.3 rpm @50Hz / 10 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P200B | GGM K9P gearhead K9P200B — ratio 1/200, output 7.5/9 rpm (50/60Hz), □90mm | GGM | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/200 | Output Speed: 7.5 rpm @50Hz / 9 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm | ||
| K9P10BX | GGM K9P decimal gearhead K9P10BX — 1/10 sub-ratio, □90mm | GGM | Type: Decimal Gearhead | Gear Ratio: 1/10 (sub-ratio) | Max Permissible Torque: 20 N·m / 200 kgf·cm | Note: Installed between motor and gearhead for ratios finer than 1/3 |
