[GGM] — K6H□B Solid-Shaft Gearhead (for K6 30W Brushless Motor Unit, ø10 solid, 1/5~1/200)
Family ID: GGM-K6H-B
GGM K6H□B inline solid-shaft gearhead for K6 30W brushless AC/DC motor units, with ø10 keyed output shaft and □60 flange (ø70 P.C.D). Deceleration ratios 1/5 to 1/200 (8 steps), allowed output torque up to 6 N·m, 81–90% efficiency; motor sold separately.
8 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| K6H5B | GGM K6H□B inline solid-shaft gearhead, ratio 1/5, ø10 keyed shaft, for K6 30W brushless motor unit | GGM | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/5 | Output Speed Range: 20~600 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 0.45 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 90% | Allowed Overhang Load: 100 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×50 (set included) | ||
| K6H10B | GGM K6H□B inline solid-shaft gearhead, ratio 1/10, ø10 keyed shaft, for K6 30W brushless motor unit | GGM | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/10 | Output Speed Range: 10~300 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 0.9 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 90% | Allowed Overhang Load: 150 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×50 (set included) | ||
| K6H15B | GGM K6H□B inline solid-shaft gearhead, ratio 1/15, ø10 keyed shaft, for K6 30W brushless motor unit | GGM | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/15 | Output Speed Range: 6.7~200 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 1.4 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 90% | Allowed Overhang Load: 150 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×50 (set included) | ||
| K6H20B | GGM K6H□B inline solid-shaft gearhead, ratio 1/20, ø10 keyed shaft, for K6 30W brushless motor unit | GGM | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/20 | Output Speed Range: 5~150 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 1.8 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 90% | Allowed Overhang Load: 150 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×50 (set included) | ||
| K6H30B | GGM K6H□B inline solid-shaft gearhead, ratio 1/30, ø10 keyed shaft, for K6 30W brushless motor unit | GGM | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/30 | Output Speed Range: 3.3~100 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 2.6 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 86% | Allowed Overhang Load: 200 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×55 (set included) | ||
| K6H50B | GGM K6H□B inline solid-shaft gearhead, ratio 1/50, ø10 keyed shaft, for K6 30W brushless motor unit | GGM | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/50 | Output Speed Range: 2~60 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 4.3 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 86% | Allowed Overhang Load: 200 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×55 (set included) | ||
| K6H100B | GGM K6H□B inline solid-shaft gearhead, ratio 1/100, ø10 keyed shaft, for K6 30W brushless motor unit | GGM | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/100 | Output Speed Range: 1~30 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 6 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 86% | Allowed Overhang Load: 200 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×55 (set included) | ||
| K6H200B | GGM K6H□B inline solid-shaft gearhead, ratio 1/200, ø10 keyed shaft, for K6 30W brushless motor unit | GGM | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/200 | Output Speed Range: 0.5~15 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 6 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 81% | Allowed Overhang Load: 200 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×60 (set included) |
