Gearheads
GGM
[GGM] — K9P□BUF Gearhead for □90 60–200W Geared Motors (□90mm, 1/3–1/200, ø18 Heavy-Duty Shaft, 130mm Flange, Cap 20 N·m)
Family ID: GGM-K9P-BUF
GGM K9P-BUF parallel-shaft gearhead for □90mm 60–200W GGM geared motors, sold separately. Heavy-duty ø18 (h7) keyed output shaft (extended output stage) with 130mm output flange (110±0.5, 4-ø8.5 holes + 4-M6 tap). 24 gear ratios 1/3–1/200, max permissible torque 20 N·m / 200 kgf·cm (per K9P B/BF rating). Shares decimal gearhead K9P10BX.
24 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| K9P3BUF | GGM K9P gearhead K9P3BUF — ratio 1/3, output 500/600 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/3 | Output Speed: 500 rpm @50Hz / 600 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P3.6BUF | GGM K9P gearhead K9P3.6BUF — ratio 1/3.6, output 416/500 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/3.6 | Output Speed: 416 rpm @50Hz / 500 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P5BUF | GGM K9P gearhead K9P5BUF — ratio 1/5, output 300/360 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/5 | Output Speed: 300 rpm @50Hz / 360 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P6BUF | GGM K9P gearhead K9P6BUF — ratio 1/6, output 250/300 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/6 | Output Speed: 250 rpm @50Hz / 300 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P7.5BUF | GGM K9P gearhead K9P7.5BUF — ratio 1/7.5, output 200/240 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/7.5 | Output Speed: 200 rpm @50Hz / 240 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P9BUF | GGM K9P gearhead K9P9BUF — ratio 1/9, output 166/200 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/9 | Output Speed: 166 rpm @50Hz / 200 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P10BUF | GGM K9P gearhead K9P10BUF — ratio 1/10, output 150/180 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/10 | Output Speed: 150 rpm @50Hz / 180 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P12.5BUF | GGM K9P gearhead K9P12.5BUF — ratio 1/12.5, output 120/144 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/12.5 | Output Speed: 120 rpm @50Hz / 144 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P15BUF | GGM K9P gearhead K9P15BUF — ratio 1/15, output 100/120 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/15 | Output Speed: 100 rpm @50Hz / 120 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P18BUF | GGM K9P gearhead K9P18BUF — ratio 1/18, output 83/100 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/18 | Output Speed: 83 rpm @50Hz / 100 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P20BUF | GGM K9P gearhead K9P20BUF — ratio 1/20, output 75/90 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/20 | Output Speed: 75 rpm @50Hz / 90 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P25BUF | GGM K9P gearhead K9P25BUF — ratio 1/25, output 60/72 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/25 | Output Speed: 60 rpm @50Hz / 72 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P30BUF | GGM K9P gearhead K9P30BUF — ratio 1/30, output 50/60 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/30 | Output Speed: 50 rpm @50Hz / 60 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P36BUF | GGM K9P gearhead K9P36BUF — ratio 1/36, output 41/50 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/36 | Output Speed: 41 rpm @50Hz / 50 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P40BUF | GGM K9P gearhead K9P40BUF — ratio 1/40, output 37/45 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/40 | Output Speed: 37 rpm @50Hz / 45 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P50BUF | GGM K9P gearhead K9P50BUF — ratio 1/50, output 30/36 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/50 | Output Speed: 30 rpm @50Hz / 36 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P60BUF | GGM K9P gearhead K9P60BUF — ratio 1/60, output 25/30 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/60 | Output Speed: 25 rpm @50Hz / 30 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P75BUF | GGM K9P gearhead K9P75BUF — ratio 1/75, output 20/24 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/75 | Output Speed: 20 rpm @50Hz / 24 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P90BUF | GGM K9P gearhead K9P90BUF — ratio 1/90, output 16/20 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/90 | Output Speed: 16 rpm @50Hz / 20 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P100BUF | GGM K9P gearhead K9P100BUF — ratio 1/100, output 15/18 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/100 | Output Speed: 15 rpm @50Hz / 18 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P120BUF | GGM K9P gearhead K9P120BUF — ratio 1/120, output 12.5/15 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/120 | Output Speed: 12.5 rpm @50Hz / 15 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P150BUF | GGM K9P gearhead K9P150BUF — ratio 1/150, output 10/12 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/150 | Output Speed: 10 rpm @50Hz / 12 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P180BUF | GGM K9P gearhead K9P180BUF — ratio 1/180, output 8.3/10 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/180 | Output Speed: 8.3 rpm @50Hz / 10 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) | ||
| K9P200BUF | GGM K9P gearhead K9P200BUF — ratio 1/200, output 7.5/9 rpm (50/60Hz), □90mm, ø18 | GGM | Type: Gearhead (Parallel Shaft, ø18 Heavy-Duty Output, 130mm Flange) | Gear Ratio: 1/200 | Output Speed: 7.5 rpm @50Hz / 9 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm (per K9P B/BF table) |
