[GGM] — K8G□BRS Right-Angle Solid-Shaft Gearhead (□80, for 25W motor, 8 N·m, 1/3~1/180)
Gearheads GGM

[GGM] — K8G□BRS Right-Angle Solid-Shaft Gearhead (□80, for 25W motor, 8 N·m, 1/3~1/180)

Family ID: GGM-K8G-BRS

GGM K8G□BRS right-angle solid-shaft gearhead for □80 frame 25W induction motors, with ø10 keyed output shaft (h7) and M5 mounting bolts. Gear ratios 1/3 to 1/180 (20 steps), output speed 8.3–500 rpm, max permissible torque 8 N·m; motor sold separately.

20 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
K8G3BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/3, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/3 | Output Speed: 500 rpm (50Hz) / 600 rpm (60Hz) | Rated Torque: 0.28 N·m (50Hz) / 0.23 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G3.6BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/3.6, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/3.6 | Output Speed: 416 rpm (50Hz) / 500 rpm (60Hz) | Rated Torque: 0.33 N·m (50Hz) / 0.28 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G5BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/5, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/5 | Output Speed: 300 rpm (50Hz) / 360 rpm (60Hz) | Rated Torque: 0.46 N·m (50Hz) / 0.39 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G6BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/6, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/6 | Output Speed: 250 rpm (50Hz) / 300 rpm (60Hz) | Rated Torque: 0.56 N·m (50Hz) / 0.47 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G7.5BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/7.5, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/7.5 | Output Speed: 200 rpm (50Hz) / 240 rpm (60Hz) | Rated Torque: 0.69 N·m (50Hz) / 0.58 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G9BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/9, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/9 | Output Speed: 166 rpm (50Hz) / 200 rpm (60Hz) | Rated Torque: 0.83 N·m (50Hz) / 0.70 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G12.5BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/12.5, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/12.5 | Output Speed: 120 rpm (50Hz) / 144 rpm (60Hz) | Rated Torque: 1.57 N·m (50Hz) / 1.32 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G15BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/15, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/15 | Output Speed: 100 rpm (50Hz) / 120 rpm (60Hz) | Rated Torque: 1.89 N·m (50Hz) / 1.58 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G18BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/18, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/18 | Output Speed: 83 rpm (50Hz) / 100 rpm (60Hz) | Rated Torque: 2.26 N·m (50Hz) / 1.90 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G25BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/25, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/25 | Output Speed: 60 rpm (50Hz) / 72 rpm (60Hz) | Rated Torque: 3.15 N·m (50Hz) / 2.64 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G30BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/30, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/30 | Output Speed: 50 rpm (50Hz) / 60 rpm (60Hz) | Rated Torque: 3.77 N·m (50Hz) / 3.16 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G36BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/36, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/36 | Output Speed: 42 rpm (50Hz) / 50 rpm (60Hz) | Rated Torque: 4.53 N·m (50Hz) / 3.79 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G50BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/50, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/50 | Output Speed: 30 rpm (50Hz) / 36 rpm (60Hz) | Rated Torque: 6.29 N·m (50Hz) / 5.27 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G60BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/60, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/60 | Output Speed: 25 rpm (50Hz) / 30 rpm (60Hz) | Rated Torque: 7.55 N·m (50Hz) / 6.32 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G75BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/75, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/75 | Output Speed: 20 rpm (50Hz) / 24 rpm (60Hz) | Rated Torque: 8 N·m (50Hz) / 7.91 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G90BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/90, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/90 | Output Speed: 17 rpm (50Hz) / 20 rpm (60Hz) | Rated Torque: 8 N·m (50Hz) / 8 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G100BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/100, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/100 | Output Speed: 15 rpm (50Hz) / 18 rpm (60Hz) | Rated Torque: 8 N·m (50Hz) / 8 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G120BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/120, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/120 | Output Speed: 12.5 rpm (50Hz) / 15.0 rpm (60Hz) | Rated Torque: 8 N·m (50Hz) / 8 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G150BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/150, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/150 | Output Speed: 10 rpm (50Hz) / 12 rpm (60Hz) | Rated Torque: 8 N·m (50Hz) / 8 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
K8G180BRS GGM K8G□BRS right-angle solid-shaft gearhead, ratio 1/180, ø10 keyed shaft, □80/25W GGM Type: Right-Angle Solid-Shaft Gearhead | Frame: □80 (for 25W, K8I□25N□) | Gear Ratio: 1/180 | Output Speed: 8.3 rpm (50Hz) / 10.0 rpm (60Hz) | Rated Torque: 8 N·m (50Hz) / 8 N·m (60Hz) | Max Permissible Torque: 8 N·m (80 kgf·cm) | Output Shaft: ø10 solid, key type | Mounting: M5 P0.8
