![[GGM] — K6G Gearhead for □60 Motors (1/3–1/250, max 3 N·m / 30 kgf·cm)](https://img.prosourcemro.com/2026/06/0604-31-857x1024.png)
Gearheads
GGM
[GGM] — K6G Gearhead for □60 Motors (1/3–1/250, max 3 N·m / 30 kgf·cm)
Family ID: GGM-K6G
GGM K6G parallel-shaft gearhead for □60 K6 AC-induction and K6D DC motors, 25 gear ratios from 1/3 to 1/250 plus a K6G10BX 1/10 decimal gearhead. Max permissible output torque 3 N·m (30 kgf·cm); output speed = motor speed ÷ ratio. Sold separately.
26 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| K6G3B | K6G gearhead, 1/3, output 500/600 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/3 | Output Speed (4-pole AC input): 500 rpm (50Hz) / 600 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G3.6B | K6G gearhead, 1/3.6, output 416/500 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/3.6 | Output Speed (4-pole AC input): 416 rpm (50Hz) / 500 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G5B | K6G gearhead, 1/5, output 300/360 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/5 | Output Speed (4-pole AC input): 300 rpm (50Hz) / 360 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G6B | K6G gearhead, 1/6, output 250/300 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/6 | Output Speed (4-pole AC input): 250 rpm (50Hz) / 300 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G7.5B | K6G gearhead, 1/7.5, output 200/240 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/7.5 | Output Speed (4-pole AC input): 200 rpm (50Hz) / 240 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G9B | K6G gearhead, 1/9, output 166/200 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/9 | Output Speed (4-pole AC input): 166 rpm (50Hz) / 200 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G10B | K6G gearhead, 1/10, output 150/180 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/10 | Output Speed (4-pole AC input): 150 rpm (50Hz) / 180 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G12.5B | K6G gearhead, 1/12.5, output 120/144 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/12.5 | Output Speed (4-pole AC input): 120 rpm (50Hz) / 144 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G15B | K6G gearhead, 1/15, output 100/120 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/15 | Output Speed (4-pole AC input): 100 rpm (50Hz) / 120 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G18B | K6G gearhead, 1/18, output 83/100 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/18 | Output Speed (4-pole AC input): 83 rpm (50Hz) / 100 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G20B | K6G gearhead, 1/20, output 75/90 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/20 | Output Speed (4-pole AC input): 75 rpm (50Hz) / 90 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G25B | K6G gearhead, 1/25, output 60/72 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/25 | Output Speed (4-pole AC input): 60 rpm (50Hz) / 72 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G30B | K6G gearhead, 1/30, output 50/60 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/30 | Output Speed (4-pole AC input): 50 rpm (50Hz) / 60 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G36B | K6G gearhead, 1/36, output 41/50 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/36 | Output Speed (4-pole AC input): 41 rpm (50Hz) / 50 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G40B | K6G gearhead, 1/40, output 37/45 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/40 | Output Speed (4-pole AC input): 37 rpm (50Hz) / 45 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G50B | K6G gearhead, 1/50, output 30/36 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed (4-pole AC input): 30 rpm (50Hz) / 36 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G60B | K6G gearhead, 1/60, output 25/30 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/60 | Output Speed (4-pole AC input): 25 rpm (50Hz) / 30 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G75B | K6G gearhead, 1/75, output 20/24 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/75 | Output Speed (4-pole AC input): 20 rpm (50Hz) / 24 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G90B | K6G gearhead, 1/90, output 16/20 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/90 | Output Speed (4-pole AC input): 16 rpm (50Hz) / 20 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G100B | K6G gearhead, 1/100, output 15/18 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/100 | Output Speed (4-pole AC input): 15 rpm (50Hz) / 18 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G120B | K6G gearhead, 1/120, output 12.5/15 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/120 | Output Speed (4-pole AC input): 12.5 rpm (50Hz) / 15 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G150B | K6G gearhead, 1/150, output 10/12 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/150 | Output Speed (4-pole AC input): 10 rpm (50Hz) / 12 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G180B | K6G gearhead, 1/180, output 8.3/10 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/180 | Output Speed (4-pole AC input): 8.3 rpm (50Hz) / 10 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G200B | K6G gearhead, 1/200, output 7.5/9 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/200 | Output Speed (4-pole AC input): 7.5 rpm (50Hz) / 9 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G250B | K6G gearhead, 1/250, output 6/7.2 rpm @ 50/60Hz (4-pole AC), max 30 kgf·cm | GGM | Gear Ratio: 1/250 | Output Speed (4-pole AC input): 6 rpm (50Hz) / 7.2 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | ||
| K6G10BX | K6G10BX decimal gearhead, 1/10, in-line between motor and gearhead, max 30 kgf·cm | GGM | Gear Ratio: 1/10 (decimal, in-line) | Output Speed (4-pole AC input): 150 rpm (50Hz) / 180 rpm (60Hz) | Max Permissible Output Torque: 3 N·m (30 kgf·cm) | Use: mounted between motor and gearhead to extend reduction range |
