[GGM] — K9P□BRH Right-Angle Hollow-Shaft Gearhead (□90, for 60/90/120W motor, 20 N·m, 1/3~1/180)
Gearheads GGM

[GGM] — K9P□BRH Right-Angle Hollow-Shaft Gearhead (□90, for 60/90/120W motor, 20 N·m, 1/3~1/180)

Family ID: GGM-K9P-BRH

GGM K9P□BRH right-angle hollow-shaft gearhead for □90 frame 60/90/120W induction motors, with ø17 hollow output bore (H8) and M6 mounting bolts. Gear ratios 1/3 to 1/180 (20 steps), output speed 8.3–500 rpm, max permissible torque 20 N·m; motor sold separately.

20 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
K9P3BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/3, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/3 | Output Speed: 500 rpm (50Hz) / 600 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P3.6BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/3.6, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/3.6 | Output Speed: 416 rpm (50Hz) / 500 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P5BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/5, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/5 | Output Speed: 300 rpm (50Hz) / 360 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P6BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/6, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/6 | Output Speed: 250 rpm (50Hz) / 300 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P7.5BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/7.5, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/7.5 | Output Speed: 200 rpm (50Hz) / 240 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P9BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/9, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/9 | Output Speed: 166 rpm (50Hz) / 200 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P12.5BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/12.5, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/12.5 | Output Speed: 120 rpm (50Hz) / 144 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P15BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/15, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/15 | Output Speed: 100 rpm (50Hz) / 120 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P18BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/18, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/18 | Output Speed: 83 rpm (50Hz) / 100 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P25BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/25, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/25 | Output Speed: 60 rpm (50Hz) / 72 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P30BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/30, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/30 | Output Speed: 50 rpm (50Hz) / 60 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P36BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/36, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/36 | Output Speed: 42 rpm (50Hz) / 50 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P50BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/50, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/50 | Output Speed: 30 rpm (50Hz) / 36 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P60BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/60, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/60 | Output Speed: 25 rpm (50Hz) / 30 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P75BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/75, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/75 | Output Speed: 20 rpm (50Hz) / 24 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P90BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/90, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/90 | Output Speed: 17 rpm (50Hz) / 20 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P100BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/100, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/100 | Output Speed: 15 rpm (50Hz) / 18 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P120BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/120, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/120 | Output Speed: 12.5 rpm (50Hz) / 15 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P150BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/150, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/150 | Output Speed: 10 rpm (50Hz) / 12 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
K9P180BRH GGM K9P□BRH right-angle hollow-shaft gearhead, ratio 1/180, ø17 hollow bore, □90/60-120W GGM Type: Right-Angle Hollow-Shaft Gearhead | Frame: □90 (for K9I□60F/90F/120F, 60/90/120W) | Gear Ratio: 1/180 | Output Speed: 8.3 rpm (50Hz) / 10 rpm (60Hz) | Max Permissible Torque: 20 N·m (200 kgf·cm) | Output Shaft: ø17 hollow bore (H8), key type | Mounting: M6 P1.0
