[THK] — Cross Roller Table VRU3 (W60×H28, M4)
Family ID: THK-VRU3
THK VRU Cross Roller Table, VRU3 frame. Table width W=60mm, height M=28mm, table mounting tap M4. Base mounting through-hole d×D×h = 4.5×7.5×5mm. Stroke range 30~130mm. Side mounting taps provided. Stainless steel type available on request (approx. 0.28~0.97 kg).
7 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| VRU3055 | THK Cross Roller Table VRU3055, stroke 30mm, 6 rollers, 0.57kg | THK | Frame: VRU3 | Table Width (W): 60 mm | Height (M): 28 mm | Stroke: 30 mm | Rollers (Z): 6 | Mass (standard): 0.57 kg | Mass (stainless): 0.3 kg | Basic Dynamic Load Rating C: 2.71 kN | Basic Static Load Rating C0: 3.67 kN | Static Allowable Moment MA: 12.2 N·m | Static Allowable Moment MB: 13.9 N·m | Static Allowable Moment MC: 51.3 N·m | Table Mounting Tap: M4 | Base Hole (d×D×h): 4.5×7.5×5 mm | Stainless Type: available on request | ||
| VRU3080 | THK Cross Roller Table VRU3080, stroke 45mm, 10 rollers, 0.8kg | THK | Frame: VRU3 | Table Width (W): 60 mm | Height (M): 28 mm | Stroke: 45 mm | Rollers (Z): 10 | Mass (standard): 0.8 kg | Mass (stainless): 0.4 kg | Basic Dynamic Load Rating C: 4.06 kN | Basic Static Load Rating C0: 6.11 kN | Static Allowable Moment MA: 33.1 N·m | Static Allowable Moment MB: 36.2 N·m | Static Allowable Moment MC: 85.5 N·m | Table Mounting Tap: M4 | Base Hole (d×D×h): 4.5×7.5×5 mm | Stainless Type: available on request | ||
| VRU3105 | THK Cross Roller Table VRU3105, stroke 60mm, 13 rollers, 1.03kg | THK | Frame: VRU3 | Table Width (W): 60 mm | Height (M): 28 mm | Stroke: 60 mm | Rollers (Z): 13 | Mass (standard): 1.03 kg | Mass (stainless): 0.6 kg | Basic Dynamic Load Rating C: 4.68 kN | Basic Static Load Rating C0: 7.33 kN | Static Allowable Moment MA: 64.6 N·m | Static Allowable Moment MB: 59.8 N·m | Static Allowable Moment MC: 103.0 N·m | Table Mounting Tap: M4 | Base Hole (d×D×h): 4.5×7.5×5 mm | Stainless Type: available on request | ||
| VRU3130 | THK Cross Roller Table VRU3130, stroke 75mm, 17 rollers, 1.26kg | THK | Frame: VRU3 | Table Width (W): 60 mm | Height (M): 28 mm | Stroke: 75 mm | Rollers (Z): 17 | Mass (standard): 1.26 kg | Mass (stainless): 0.7 kg | Basic Dynamic Load Rating C: 5.87 kN | Basic Static Load Rating C0: 9.77 kN | Static Allowable Moment MA: 107.0 N·m | Static Allowable Moment MB: 100.0 N·m | Static Allowable Moment MC: 137.0 N·m | Table Mounting Tap: M4 | Base Hole (d×D×h): 4.5×7.5×5 mm | Stainless Type: available on request | ||
| VRU3155 | THK Cross Roller Table VRU3155, stroke 90mm, 20 rollers, 1.49kg | THK | Frame: VRU3 | Table Width (W): 60 mm | Height (M): 28 mm | Stroke: 90 mm | Rollers (Z): 20 | Mass (standard): 1.49 kg | Mass (stainless): 0.9 kg | Basic Dynamic Load Rating C: 6.98 kN | Basic Static Load Rating C0: 12.2 kN | Static Allowable Moment MA: 131.0 N·m | Static Allowable Moment MB: 138.0 N·m | Static Allowable Moment MC: 171.0 N·m | Table Mounting Tap: M4 | Base Hole (d×D×h): 4.5×7.5×5 mm | Stainless Type: available on request | ||
| VRU3180 | THK Cross Roller Table VRU3180, stroke 105mm, 24 rollers, 1.72kg | THK | Frame: VRU3 | Table Width (W): 60 mm | Height (M): 28 mm | Stroke: 105 mm | Rollers (Z): 24 | Mass (standard): 1.72 kg | Mass (stainless): 1.0 kg | Basic Dynamic Load Rating C: 8.05 kN | Basic Static Load Rating C0: 14.7 kN | Static Allowable Moment MA: 189.0 N·m | Static Allowable Moment MB: 196.0 N·m | Static Allowable Moment MC: 205.0 N·m | Table Mounting Tap: M4 | Base Hole (d×D×h): 4.5×7.5×5 mm | Stainless Type: available on request | ||
| VRU3205 | THK Cross Roller Table VRU3205, stroke 130mm, 26 rollers, 1.95kg | THK | Frame: VRU3 | Table Width (W): 60 mm | Height (M): 28 mm | Stroke: 130 mm | Rollers (Z): 26 | Mass (standard): 1.95 kg | Mass (stainless): 1.1 kg | Basic Dynamic Load Rating C: 8.57 kN | Basic Static Load Rating C0: 15.9 kN | Static Allowable Moment MA: 222.0 N·m | Static Allowable Moment MB: 230.0 N·m | Static Allowable Moment MC: 222.0 N·m | Table Mounting Tap: M4 | Base Hole (d×D×h): 4.5×7.5×5 mm | Stainless Type: available on request |
