[THK] — HSR-M1-A/LA High Temperature LM Guide Block (Flange Tapped, Stainless, 150°C)
Family ID: THK-HSR-M1-A
High temperature type HSR LM Guide. Flange type with tapped holes. Stainless end plate and high-temp rubber end seal — max 150°C operating temperature. Dimensional stabilization treatment for stability after heating/cooling cycles. Stainless block, rail and balls — ideal for clean rooms. Low rolling resistance variation with high-temp grease.
9 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| HSR-15M1A | HSR 15M1A LM Block H24×W47×L59.6mm | THK | Type: High Temperature LM Guide Block | Series: HSR-M1 | Model: HSR 15M1A | Height M: 24 mm | Width W: 47 mm | Length L: 59.6 mm | Max Rail Length: 1240 mm | Dynamic Load C: 10.9 kN | Static Load C0: 15.7 kN | Max Temperature: 150°C | Material: Stainless Steel | Mount: Flange Tapped | Application: High-temp / Clean room | Brand: THK | ||
| HSR-20M1A | HSR 20M1A LM Block H30×W63×L76mm | THK | Type: High Temperature LM Guide Block | Series: HSR-M1 | Model: HSR 20M1A | Height M: 30 mm | Width W: 63 mm | Length L: 76 mm | Max Rail Length: 1480 mm | Dynamic Load C: 19.8 kN | Static Load C0: 27.4 kN | Max Temperature: 150°C | Material: Stainless Steel | Mount: Flange Tapped | Application: High-temp / Clean room | Brand: THK | ||
| HSR-20M1LA | HSR 20M1LA LM Block H30×W63×L92mm | THK | Type: High Temperature LM Guide Block | Series: HSR-M1 | Model: HSR 20M1LA | Height M: 30 mm | Width W: 63 mm | Length L: 92 mm | Max Rail Length: 1480 mm | Dynamic Load C: 23.9 kN | Static Load C0: 35.8 kN | Max Temperature: 150°C | Material: Stainless Steel | Mount: Flange Tapped | Application: High-temp / Clean room | Brand: THK | ||
| HSR-25M1A | HSR 25M1A LM Block H36×W70×L83.9mm | THK | Type: High Temperature LM Guide Block | Series: HSR-M1 | Model: HSR 25M1A | Height M: 36 mm | Width W: 70 mm | Length L: 83.9 mm | Max Rail Length: 1500 mm | Dynamic Load C: 27.6 kN | Static Load C0: 36.4 kN | Max Temperature: 150°C | Material: Stainless Steel | Mount: Flange Tapped | Application: High-temp / Clean room | Brand: THK | ||
| HSR-25M1LA | HSR 25M1LA LM Block H36×W70×L103mm | THK | Type: High Temperature LM Guide Block | Series: HSR-M1 | Model: HSR 25M1LA | Height M: 36 mm | Width W: 70 mm | Length L: 103 mm | Max Rail Length: 1500 mm | Dynamic Load C: 35.2 kN | Static Load C0: 51.6 kN | Max Temperature: 150°C | Material: Stainless Steel | Mount: Flange Tapped | Application: High-temp / Clean room | Brand: THK | ||
| HSR-30M1A | HSR 30M1A LM Block H42×W90×L98.8mm | THK | Type: High Temperature LM Guide Block | Series: HSR-M1 | Model: HSR 30M1A | Height M: 42 mm | Width W: 90 mm | Length L: 98.8 mm | Max Rail Length: 1500 mm | Dynamic Load C: 40.5 kN | Static Load C0: 53.7 kN | Max Temperature: 150°C | Material: Stainless Steel | Mount: Flange Tapped | Application: High-temp / Clean room | Brand: THK | ||
| HSR-30M1LA | HSR 30M1LA LM Block H42×W90×L121.4mm | THK | Type: High Temperature LM Guide Block | Series: HSR-M1 | Model: HSR 30M1LA | Height M: 42 mm | Width W: 90 mm | Length L: 121.4 mm | Max Rail Length: 1500 mm | Dynamic Load C: 48.9 kN | Static Load C0: 70.2 kN | Max Temperature: 150°C | Material: Stainless Steel | Mount: Flange Tapped | Application: High-temp / Clean room | Brand: THK | ||
| HSR-35M1A | HSR 35M1A LM Block H48×W100×L112mm | THK | Type: High Temperature LM Guide Block | Series: HSR-M1 | Model: HSR 35M1A | Height M: 48 mm | Width W: 100 mm | Length L: 112 mm | Max Rail Length: 1500 mm | Dynamic Load C: 53.9 kN | Static Load C0: 70.2 kN | Max Temperature: 150°C | Material: Stainless Steel | Mount: Flange Tapped | Application: High-temp / Clean room | Brand: THK | ||
| HSR-35M1LA | HSR 35M1LA LM Block H48×W100×L137.4mm | THK | Type: High Temperature LM Guide Block | Series: HSR-M1 | Model: HSR 35M1LA | Height M: 48 mm | Width W: 100 mm | Length L: 137.4 mm | Max Rail Length: 1500 mm | Dynamic Load C: 65 kN | Static Load C0: 91.7 kN | Max Temperature: 150°C | Material: Stainless Steel | Mount: Flange Tapped | Application: High-temp / Clean room | Brand: THK |
