[THK] — HSR-RM Miniature LM Guide Block (Full Ball, Stainless, High Rigidity)
Family ID: THK-HSR-RM
Miniature Full ball type LM Guide. HSR miniature series — stainless steel rail, block and balls. 4-direction equal load rating with 45° ball arrangement. 4-row configuration for high rigidity. THK Circular Arc groove (DF structure).
3 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| HSR-8RM | HSR 8RM LM Block H11×W16×L24mm | THK | Type: Miniature LM Guide Block | Series: HSR | Model: HSR 8RM | Height M: 11 mm | Width W: 16 mm | Length L: 24 mm | Max Rail Length: 975 mm | Dynamic Load C: 1.08 kN | Static Load C0: 2.16 kN | Material: Stainless Steel | Structure: Full Ball DF | Load Type: 4-Direction Equal | Configuration: 4-row High Rigidity | Brand: THK | ||
| HSR-10RM | HSR 10RM LM Block H13×W20×L31mm | THK | Type: Miniature LM Guide Block | Series: HSR | Model: HSR 10RM | Height M: 13 mm | Width W: 20 mm | Length L: 31 mm | Max Rail Length: 995 mm | Dynamic Load C: 1.96 kN | Static Load C0: 3.82 kN | Material: Stainless Steel | Structure: Full Ball DF | Load Type: 4-Direction Equal | Configuration: 4-row High Rigidity | Brand: THK | ||
| HSR-12RM | HSR 12RM LM Block H20×W27×L45mm | THK | Type: Miniature LM Guide Block | Series: HSR | Model: HSR 12RM | Height M: 20 mm | Width W: 27 mm | Length L: 45 mm | Max Rail Length: 1240 mm | Dynamic Load C: 4.7 kN | Static Load C0: 8.53 kN | Material: Stainless Steel | Structure: Full Ball DF | Load Type: 4-Direction Equal | Configuration: 4-row High Rigidity | Brand: THK |
