[THK] — Cam Follower CFT (Lubrication Tap Type)

Family ID: THK-CFT

THK CFT type Cam Follower with lubrication tap hole on stud head and thread. Optimized for centralized piping lubrication systems. CFT6~10-1: M6×0.75 tap on head only. CFT12~12-1: M6×0.75 tap both ends. CFT16 and larger: Rc1/8 (PT1/8) tap both ends. Stud diameter d = 6~30mm. Options: V (full needle), M (stainless), UU (seal), R (spherical outer ring). Spherical radius: R500 (CFT18 or smaller) / R1000 (CFT20 or larger).

15 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
CFT6 THK Cam Follower CFT6 (lube tap), d=6mm, D=16mm, C(cage)=3.59kN THK Stud Diameter (d): 6 mm | Outer Diameter (D): 16 mm | Outer Ring Width (C): 11 mm | Stud Thread: M6×1 | Total Length (B): 28 mm | Lubrication Tap: M6×0.75 (head only) | Basic Dynamic Load Rating C (cage): 3.59 kN | Basic Static Load Rating C0 (cage): 3.58 kN | Basic Dynamic Load Rating C (full needle): 6.94 kN | Basic Static Load Rating C0 (full needle): 8.5 kN | Max Allowable Load F0 (cylindrical): 2.11 kN | Max Allowable Load F0 (spherical): 3.43 kN | Track Load Capacity (full needle): 1.08 kN | Limit Speed (cage): 25000 min⁻¹ | Limit Speed (full needle): 11000 min⁻¹ | Mass (cage): 18.5 g | Mass (full needle): 19.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R500
CFT8 THK Cam Follower CFT8 (lube tap), d=8mm, D=19mm, C(cage)=4.17kN THK Stud Diameter (d): 8 mm | Outer Diameter (D): 19 mm | Outer Ring Width (C): 11 mm | Stud Thread: M8×1.25 | Total Length (B): 32 mm | Lubrication Tap: M6×0.75 (head only) | Basic Dynamic Load Rating C (cage): 4.17 kN | Basic Static Load Rating C0 (cage): 4.65 kN | Basic Dynamic Load Rating C (full needle): 8.13 kN | Basic Static Load Rating C0 (full needle): 11.2 kN | Max Allowable Load F0 (cylindrical): 4.73 kN | Max Allowable Load F0 (spherical): 4.02 kN | Track Load Capacity (full needle): 1.37 kN | Limit Speed (cage): 20000 min⁻¹ | Limit Speed (full needle): 8700 min⁻¹ | Mass (cage): 28.5 g | Mass (full needle): 29.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R500
CFT10 THK Cam Follower CFT10 (lube tap), d=10mm, D=22mm, C(cage)=5.33kN THK Stud Diameter (d): 10 mm | Outer Diameter (D): 22 mm | Outer Ring Width (C): 12 mm | Stud Thread: M10×1.25 | Total Length (B): 36 mm | Lubrication Tap: M6×0.75 (head only) | Basic Dynamic Load Rating C (cage): 5.33 kN | Basic Static Load Rating C0 (cage): 6.78 kN | Basic Dynamic Load Rating C (full needle): 9.42 kN | Basic Static Load Rating C0 (full needle): 14.3 kN | Max Allowable Load F0 (cylindrical): 5.81 kN | Max Allowable Load F0 (spherical): 4.7 kN | Track Load Capacity (full needle): 1.67 kN | Limit Speed (cage): 17000 min⁻¹ | Limit Speed (full needle): 7200 min⁻¹ | Mass (cage): 45.0 g | Mass (full needle): 46.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R500
CFT10-1 THK Cam Follower CFT10-1 (lube tap), d=10mm, D=26mm, C(cage)=5.33kN THK Stud Diameter (d): 10 mm | Outer Diameter (D): 26 mm | Outer Ring Width (C): 12 mm | Stud Thread: M10×1.25 | Total Length (B): 36 mm | Lubrication Tap: M6×0.75 (head only) | Basic Dynamic Load Rating C (cage): 5.33 kN | Basic Static Load Rating C0 (cage): 6.78 kN | Basic Dynamic Load Rating C (full needle): 9.42 kN | Basic Static Load Rating C0 (full needle): 14.3 kN | Max Allowable Load F0 (cylindrical): 5.81 kN | Max Allowable Load F0 (spherical): 5.49 kN | Track Load Capacity (full needle): 2.06 kN | Limit Speed (cage): 17000 min⁻¹ | Limit Speed (full needle): 7200 min⁻¹ | Mass (cage): 60.0 g | Mass (full needle): 61.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R500
CFT12 THK Cam Follower CFT12 (lube tap), d=12mm, D=30mm, C(cage)=7.87kN THK Stud Diameter (d): 12 mm | Outer Diameter (D): 30 mm | Outer Ring Width (C): 14 mm | Stud Thread: M12×1.5 | Total Length (B): 40 mm | Lubrication Tap: M6×0.75 (both ends) | Basic Dynamic Load Rating C (cage): 7.87 kN | Basic Static Load Rating C0 (cage): 9.79 kN | Basic Dynamic Load Rating C (full needle): 13.4 kN | Basic Static Load Rating C0 (full needle): 19.8 kN | Max Allowable Load F0 (cylindrical): 9.37 kN | Max Allowable Load F0 (spherical): 7.06 kN | Track Load Capacity (full needle): 2.45 kN | Limit Speed (cage): 14000 min⁻¹ | Limit Speed (full needle): 5800 min⁻¹ | Mass (cage): 105.0 g | Mass (full needle): 107.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R500
CFT12-1 THK Cam Follower CFT12-1 (lube tap), d=12mm, D=32mm, C(cage)=7.87kN THK Stud Diameter (d): 12 mm | Outer Diameter (D): 32 mm | Outer Ring Width (C): 14 mm | Stud Thread: M12×1.5 | Total Length (B): 40 mm | Lubrication Tap: M6×0.75 (both ends) | Basic Dynamic Load Rating C (cage): 7.87 kN | Basic Static Load Rating C0 (cage): 9.79 kN | Basic Dynamic Load Rating C (full needle): 13.4 kN | Basic Static Load Rating C0 (full needle): 19.8 kN | Max Allowable Load F0 (cylindrical): 9.37 kN | Max Allowable Load F0 (spherical): 7.45 kN | Track Load Capacity (full needle): 2.74 kN | Limit Speed (cage): 14000 min⁻¹ | Limit Speed (full needle): 5800 min⁻¹ | Mass (cage): 115.0 g | Mass (full needle): 117.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R500
CFT16 THK Cam Follower CFT16 (lube tap), d=16mm, D=35mm, C(cage)=12.0kN THK Stud Diameter (d): 16 mm | Outer Diameter (D): 35 mm | Outer Ring Width (C): 18 mm | Stud Thread: M16×1.5 | Total Length (B): 52 mm | Lubrication Tap: Rc1/8 (PT1/8) (both ends) | Basic Dynamic Load Rating C (cage): 12.0 kN | Basic Static Load Rating C0 (cage): 18.3 kN | Basic Dynamic Load Rating C (full needle): 20.6 kN | Basic Static Load Rating C0 (full needle): 37.6 kN | Max Allowable Load F0 (cylindrical): 17.3 kN | Max Allowable Load F0 (spherical): 11.2 kN | Track Load Capacity (full needle): 3.14 kN | Limit Speed (cage): 10000 min⁻¹ | Limit Speed (full needle): 4500 min⁻¹ | Mass (cage): 205.0 g | Mass (full needle): 207.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R500
CFT18 THK Cam Follower CFT18 (lube tap), d=18mm, D=40mm, C(cage)=14.7kN THK Stud Diameter (d): 18 mm | Outer Diameter (D): 40 mm | Outer Ring Width (C): 20 mm | Stud Thread: M18×1.5 | Total Length (B): 58 mm | Lubrication Tap: Rc1/8 (PT1/8) (both ends) | Basic Dynamic Load Rating C (cage): 14.7 kN | Basic Static Load Rating C0 (cage): 25.2 kN | Basic Dynamic Load Rating C (full needle): 25.2 kN | Basic Static Load Rating C0 (full needle): 51.3 kN | Max Allowable Load F0 (cylindrical): 26.1 kN | Max Allowable Load F0 (spherical): 14.4 kN | Track Load Capacity (full needle): 3.72 kN | Limit Speed (cage): 8500 min⁻¹ | Limit Speed (full needle): 3800 min⁻¹ | Mass (cage): 295.0 g | Mass (full needle): 300.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R500
CFT20 THK Cam Follower CFT20 (lube tap), d=20mm, D=52mm, C(cage)=20.7kN THK Stud Diameter (d): 20 mm | Outer Diameter (D): 52 mm | Outer Ring Width (C): 24 mm | Stud Thread: M20×1.5 | Total Length (B): 66 mm | Lubrication Tap: Rc1/8 (PT1/8) (both ends) | Basic Dynamic Load Rating C (cage): 20.7 kN | Basic Static Load Rating C0 (cage): 34.8 kN | Basic Dynamic Load Rating C (full needle): 33.2 kN | Basic Static Load Rating C0 (full needle): 64.8 kN | Max Allowable Load F0 (cylindrical): 32.1 kN | Max Allowable Load F0 (spherical): 23.2 kN | Track Load Capacity (full needle): 8.23 kN | Limit Speed (cage): 7000 min⁻¹ | Limit Speed (full needle): 3400 min⁻¹ | Mass (cage): 525.0 g | Mass (full needle): 530.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R1000
CFT20-1 THK Cam Follower CFT20-1 (lube tap), d=20mm, D=47mm, C(cage)=20.7kN THK Stud Diameter (d): 20 mm | Outer Diameter (D): 47 mm | Outer Ring Width (C): 24 mm | Stud Thread: M20×1.5 | Total Length (B): 66 mm | Lubrication Tap: Rc1/8 (PT1/8) (both ends) | Basic Dynamic Load Rating C (cage): 20.7 kN | Basic Static Load Rating C0 (cage): 34.8 kN | Basic Dynamic Load Rating C (full needle): 33.2 kN | Basic Static Load Rating C0 (full needle): 64.8 kN | Max Allowable Load F0 (cylindrical): 32.1 kN | Max Allowable Load F0 (spherical): 21.0 kN | Track Load Capacity (full needle): 7.15 kN | Limit Speed (cage): 7000 min⁻¹ | Limit Speed (full needle): 3400 min⁻¹ | Mass (cage): 450.0 g | Mass (full needle): 455.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R1000
CFT24 THK Cam Follower CFT24 (lube tap), d=24mm, D=62mm, C(cage)=30.6kN THK Stud Diameter (d): 24 mm | Outer Diameter (D): 62 mm | Outer Ring Width (C): 29 mm | Stud Thread: M24×1.5 | Total Length (B): 80 mm | Lubrication Tap: Rc1/8 (PT1/8) (both ends) | Basic Dynamic Load Rating C (cage): 30.6 kN | Basic Static Load Rating C0 (cage): 53.2 kN | Basic Dynamic Load Rating C (full needle): 46.7 kN | Basic Static Load Rating C0 (full needle): 92.9 kN | Max Allowable Load F0 (cylindrical): 49.5 kN | Max Allowable Load F0 (spherical): 34.2 kN | Track Load Capacity (full needle): 10.5 kN | Limit Speed (cage): 6500 min⁻¹ | Limit Speed (full needle): 2900 min⁻¹ | Mass (cage): 915.0 g | Mass (full needle): 925.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R1000
CFT24-1 THK Cam Follower CFT24-1 (lube tap), d=24mm, D=72mm, C(cage)=30.6kN THK Stud Diameter (d): 24 mm | Outer Diameter (D): 72 mm | Outer Ring Width (C): 29 mm | Stud Thread: M24×1.5 | Total Length (B): 80 mm | Lubrication Tap: Rc1/8 (PT1/8) (both ends) | Basic Dynamic Load Rating C (cage): 30.6 kN | Basic Static Load Rating C0 (cage): 53.2 kN | Basic Dynamic Load Rating C (full needle): 46.7 kN | Basic Static Load Rating C0 (full needle): 92.9 kN | Max Allowable Load F0 (cylindrical): 49.5 kN | Max Allowable Load F0 (spherical): 39.8 kN | Track Load Capacity (full needle): 12.9 kN | Limit Speed (cage): 6500 min⁻¹ | Limit Speed (full needle): 2900 min⁻¹ | Mass (cage): 1150.0 g | Mass (full needle): 1160.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R1000
CFT30 THK Cam Follower CFT30 (lube tap), d=30mm, D=80mm, C(cage)=45.4kN THK Stud Diameter (d): 30 mm | Outer Diameter (D): 80 mm | Outer Ring Width (C): 35 mm | Stud Thread: M30×1.5 | Total Length (B): 100 mm | Lubrication Tap: Rc1/8 (PT1/8) (both ends) | Basic Dynamic Load Rating C (cage): 45.4 kN | Basic Static Load Rating C0 (cage): 87.6 kN | Basic Dynamic Load Rating C (full needle): 67.6 kN | Basic Static Load Rating C0 (full needle): 145 kN | Max Allowable Load F0 (cylindrical): 73.7 kN | Max Allowable Load F0 (spherical): 52.6 kN | Track Load Capacity (full needle): 14.9 kN | Limit Speed (cage): 5000 min⁻¹ | Limit Speed (full needle): 2300 min⁻¹ | Mass (cage): 1880.0 g | Mass (full needle): 1890.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R1000
CFT30-1 THK Cam Follower CFT30-1 (lube tap), d=30mm, D=85mm, C(cage)=45.4kN THK Stud Diameter (d): 30 mm | Outer Diameter (D): 85 mm | Outer Ring Width (C): 35 mm | Stud Thread: M30×1.5 | Total Length (B): 100 mm | Lubrication Tap: Rc1/8 (PT1/8) (both ends) | Basic Dynamic Load Rating C (cage): 45.4 kN | Basic Static Load Rating C0 (cage): 87.6 kN | Basic Dynamic Load Rating C (full needle): 67.6 kN | Basic Static Load Rating C0 (full needle): 145 kN | Max Allowable Load F0 (cylindrical): 73.7 kN | Max Allowable Load F0 (spherical): 56.0 kN | Track Load Capacity (full needle): 16.1 kN | Limit Speed (cage): 5000 min⁻¹ | Limit Speed (full needle): 2300 min⁻¹ | Mass (cage): 1950.0 g | Mass (full needle): 1960.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R1000
CFT30-2 THK Cam Follower CFT30-2 (lube tap), d=30mm, D=90mm, C(cage)=45.4kN THK Stud Diameter (d): 30 mm | Outer Diameter (D): 90 mm | Outer Ring Width (C): 35 mm | Stud Thread: M30×1.5 | Total Length (B): 100 mm | Lubrication Tap: Rc1/8 (PT1/8) (both ends) | Basic Dynamic Load Rating C (cage): 45.4 kN | Basic Static Load Rating C0 (cage): 87.6 kN | Basic Dynamic Load Rating C (full needle): 67.6 kN | Basic Static Load Rating C0 (full needle): 145 kN | Max Allowable Load F0 (cylindrical): 73.7 kN | Max Allowable Load F0 (spherical): 59.3 kN | Track Load Capacity (full needle): 17.3 kN | Limit Speed (cage): 5000 min⁻¹ | Limit Speed (full needle): 2300 min⁻¹ | Mass (cage): 2000.0 g | Mass (full needle): 2010.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R1000
