Geared Motors

Mitsubishi Electric GM-S series parallel shaft geared motor, 0.4kW Single-Phase, W-type IP65 dust-proof and waterproof construction. 4-pole induction motor with integral helical gear reducer, flange-mount, grease-lubricated, service factor 1.0. Reduction ratios from 1/3 to 1/1200. Available with or without built-in electromagnetic brake. Efficiency class IE1. For washdown, food, and humid-environment power transmission.

Mitsubishi Electric GM-S series parallel shaft geared motor, 0.4kW Single-Phase, 4-pole induction motor with integral helical gear reducer. Flange-mount, grease-lubricated, service factor 1.0 for uniform loads. Reduction ratios from 1/3 to 1/1200 with corresponding output speeds. Available with or without built-in electromagnetic brake. Efficiency class IE1. For conveyors, mixers, and general industrial power transmission.

Mitsubishi Electric GM-S series parallel shaft geared motor, 0.4kW Single-Phase, W-type IP65 dust-proof and waterproof construction. 4-pole induction motor with integral helical gear reducer, leg-mount, grease-lubricated, service factor 1.0. Reduction ratios from 1/3 to 1/1200. Available with or without built-in electromagnetic brake. Efficiency class IE1. For washdown, food, and humid-environment power transmission.

Mitsubishi Electric GM-S series parallel shaft geared motor, 0.4kW Single-Phase, 4-pole induction motor with integral helical gear reducer. Leg-mount, grease-lubricated, service factor 1.0 for uniform loads. Reduction ratios from 1/3 to 1/1200 with corresponding output speeds. Available with or without built-in electromagnetic brake. Efficiency class IE1. For conveyors, mixers, and general industrial power transmission.

Mitsubishi Electric GM-SHY hypoid right-angle geared motor, 0.1 to 0.4kW, leg mount, service factor 1.4. Wide reduction range 1/5 to 1/1440 delivering output speeds down to 1.25 r/min at 60Hz. Compact hypoid gearing for high-reduction right-angle drives in conveyors, mixers and packaging lines. 3-phase 200/200/220V, 4-pole, grease-lubricated, insulation class 120(E), solid shaft (tapped shaft end), IP44 indoor. Output shaft direction (left / right / both) specified at order; waterproof (IP65/IP67) available on request.

Mitsubishi Electric GM-SHYB hypoid right-angle geared motor, 0.1 to 0.4kW, leg mount, service factor 1.4. Wide reduction range 1/5 to 1/1440 delivering output speeds down to 1.25 r/min at 60Hz. Compact hypoid gearing for high-reduction right-angle drives in conveyors, mixers and packaging lines. 3-phase 200/200/220V, 4-pole, grease-lubricated, insulation class 120(E), solid shaft (tapped shaft end), IP44 indoor. Built-in DC spring-applied brake for load holding. Output shaft direction (left / right / both) specified at order; waterproof (IP65/IP67) available on request.

Mitsubishi Electric GM-SHYF hypoid right-angle geared motor, 0.1 to 0.4kW, flange mount, service factor 1.4. Wide reduction range 1/5 to 1/1440 delivering output speeds down to 1.25 r/min at 60Hz. Compact hypoid gearing for high-reduction right-angle drives in conveyors, mixers and packaging lines. 3-phase 200/200/220V, 4-pole, grease-lubricated, insulation class 120(E), solid shaft (tapped shaft end), IP44 indoor. Output shaft direction (left / right / both) specified at order; waterproof (IP65/IP67) available on request.

Mitsubishi Electric GM-SHYFB hypoid right-angle geared motor, 0.1 to 0.4kW, flange mount, service factor 1.4. Wide reduction range 1/5 to 1/1440 delivering output speeds down to 1.25 r/min at 60Hz. Compact hypoid gearing for high-reduction right-angle drives in conveyors, mixers and packaging lines. 3-phase 200/200/220V, 4-pole, grease-lubricated, insulation class 120(E), solid shaft (tapped shaft end), IP44 indoor. Built-in DC spring-applied brake for load holding. Output shaft direction (left / right / both) specified at order; waterproof (IP65/IP67) available on request.

Mitsubishi Electric GM-SHYM hypoid right-angle geared motor, 0.1 to 0.4kW, face mount, service factor 1.4. Wide reduction range 1/5 to 1/1440 delivering output speeds down to 1.25 r/min at 60Hz. Compact hypoid gearing for high-reduction right-angle drives in conveyors, mixers and packaging lines. 3-phase 200/200/220V, 4-pole, grease-lubricated, insulation class 120(E), solid shaft (tapped shaft end), IP44 indoor. Output shaft direction (left / right / both) specified at order; waterproof (IP65/IP67) available on request.

Mitsubishi Electric GM-SHYMB hypoid right-angle geared motor, 0.1 to 0.4kW, face mount, service factor 1.4. Wide reduction range 1/5 to 1/1440 delivering output speeds down to 1.25 r/min at 60Hz. Compact hypoid gearing for high-reduction right-angle drives in conveyors, mixers and packaging lines. 3-phase 200/200/220V, 4-pole, grease-lubricated, insulation class 120(E), solid shaft (tapped shaft end), IP44 indoor. Built-in DC spring-applied brake for load holding. Output shaft direction (left / right / both) specified at order; waterproof (IP65/IP67) available on request.

Mitsubishi Electric GM-SHYP hypoid right-angle geared motor, 0.75 to 2.2kW, leg mount, service factor 1.4. Wide reduction range 1/5 to 1/1440 delivering output speeds down to 1.25 r/min at 60Hz. Compact hypoid gearing for high-reduction right-angle drives in conveyors, mixers and packaging lines. 3-phase 200/200/220V, 4-pole, grease-lubricated, insulation class 130(B), solid shaft (tapped shaft end), IP44 indoor. Output shaft direction (left / right / both) specified at order; waterproof (IP65/IP67) available on request.

Mitsubishi Electric GM-SHYPB hypoid right-angle geared motor, 0.75 to 2.2kW, leg mount, service factor 1.4. Wide reduction range 1/5 to 1/1440 delivering output speeds down to 1.25 r/min at 60Hz. Compact hypoid gearing for high-reduction right-angle drives in conveyors, mixers and packaging lines. 3-phase 200/200/220V, 4-pole, grease-lubricated, insulation class 130(B), solid shaft (tapped shaft end), IP44 indoor. Built-in DC spring-applied brake for load holding. Output shaft direction (left / right / both) specified at order; waterproof (IP65/IP67) available on request.

Mitsubishi Electric GM-SHYPF hypoid right-angle geared motor, 0.75 to 2.2kW, flange mount, service factor 1.4. Wide reduction range 1/5 to 1/1440 delivering output speeds down to 1.25 r/min at 60Hz. Compact hypoid gearing for high-reduction right-angle drives in conveyors, mixers and packaging lines. 3-phase 200/200/220V, 4-pole, grease-lubricated, insulation class 130(B), hollow shaft, IP44 indoor. Output shaft direction (left / right / both) specified at order; waterproof (IP65/IP67) available on request.

Mitsubishi Electric GM-SHYPFB hypoid right-angle geared motor, 0.75 to 2.2kW, flange mount, service factor 1.4. Wide reduction range 1/5 to 1/1440 delivering output speeds down to 1.25 r/min at 60Hz. Compact hypoid gearing for high-reduction right-angle drives in conveyors, mixers and packaging lines. 3-phase 200/200/220V, 4-pole, grease-lubricated, insulation class 130(B), hollow shaft, IP44 indoor. Built-in DC spring-applied brake for load holding. Output shaft direction (left / right / both) specified at order; waterproof (IP65/IP67) available on request.

Mitsubishi Electric GM-SHYPM hypoid right-angle geared motor, 0.75 to 2.2kW, face mount, service factor 1.4. Wide reduction range 1/5 to 1/1440 delivering output speeds down to 1.25 r/min at 60Hz. Compact hypoid gearing for high-reduction right-angle drives in conveyors, mixers and packaging lines. 3-phase 200/200/220V, 4-pole, grease-lubricated, insulation class 130(B), hollow shaft, IP44 indoor. Output shaft direction (left / right / both) specified at order; waterproof (IP65/IP67) available on request.
