Motors
![[GGM] — KGE-3429-P1 F-Type Offset Geared DC Motor (DC 12V, 9500rpm base, 18 ratios 1/22-1/687)](https://img.prosourcemro.com/2026/06/0605-5-300x300.png)
GGM KGE-3429-P1 f-type offset parallel-shaft geared DC motor, DC 12V (9500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard). High-torque output (12V P1 winding).
GGM KGE-3429-P1 f-type offset parallel-shaft geared DC motor, DC 12V (9500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard). High-torque output (12V P1 winding).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/22, 364rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 364 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0034-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/34, 235rpm, 2kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 235 rpm | Output Torque: 2 kgf·cm | Shaft Type: F-Type | |
| KGE-0043-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/43, 186rpm, 2.5kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 186 rpm | Output Torque: 2.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0050-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/50, 160rpm, 2.9kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 160 rpm | Output Torque: 2.9 kgf·cm | Shaft Type: F-Type | |
| KGE-0062-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/62, 129rpm, 3.6kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 129 rpm | Output Torque: 3.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0068-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/68, 117.6rpm, 4kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 117.6 rpm | Output Torque: 4 kgf·cm | Shaft Type: F-Type | |
| KGE-0083-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/83, 96.4rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 96.4 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0105-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/105, 76.2rpm, 6.1kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 76.2 rpm | Output Torque: 6.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0116-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/116, 69rpm, 6.8kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 69 rpm | Output Torque: 6.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0162-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/162, 49.4rpm, 8.5kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 49.4 rpm | Output Torque: 8.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0182-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/182, 44rpm, 9.6kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 44 rpm | Output Torque: 9.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0204-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/204, 39.2rpm, 10.7kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 39.2 rpm | Output Torque: 10.7 kgf·cm | Shaft Type: F-Type | |
| KGE-0240-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/240, 33.3rpm, 12.6kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 33.3 rpm | Output Torque: 12.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0308-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/308, 26rpm, 16.2kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 26 rpm | Output Torque: 16.2 kgf·cm | Shaft Type: F-Type | |
| KGE-0350-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/350, 22.9rpm, 18.4kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 22.9 rpm | Output Torque: 18.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0452-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/452, 17.7rpm, 20kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 17.7 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type | |
| KGE-0615-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/615, 13rpm, 20kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 13 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type | |
| KGE-0687-KD3429P1 | KGE-3429-P1 F-Type offset geared, 1/687, 11.6rpm, 20kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 11.6 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type |
GGM KGE-3429-P1 r-type offset parallel-shaft geared DC motor, DC 12V (9500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard). High-torque output (12V P1 winding).
GGM KGE-3429-P1 r-type offset parallel-shaft geared DC motor, DC 12V (9500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard). High-torque output (12V P1 winding).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/22, 364rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 364 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0034-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/34, 235rpm, 2kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 235 rpm | Output Torque: 2 kgf·cm | Shaft Type: R-Type | |
| KGE-0043-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/43, 186rpm, 2.5kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 186 rpm | Output Torque: 2.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0050-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/50, 160rpm, 2.9kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 160 rpm | Output Torque: 2.9 kgf·cm | Shaft Type: R-Type | |
| KGE-0062-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/62, 129rpm, 3.6kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 129 rpm | Output Torque: 3.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0068-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/68, 117.6rpm, 4kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 117.6 rpm | Output Torque: 4 kgf·cm | Shaft Type: R-Type | |
| KGE-0083-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/83, 96.4rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 96.4 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0105-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/105, 76.2rpm, 6.1kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 76.2 rpm | Output Torque: 6.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0116-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/116, 69rpm, 6.8kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 69 rpm | Output Torque: 6.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0162-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/162, 49.4rpm, 8.5kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 49.4 rpm | Output Torque: 8.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0182-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/182, 44rpm, 9.6kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 44 rpm | Output Torque: 9.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0204-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/204, 39.2rpm, 10.7kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 39.2 rpm | Output Torque: 10.7 kgf·cm | Shaft Type: R-Type | |
| KGE-0240-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/240, 33.3rpm, 12.6kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 33.3 rpm | Output Torque: 12.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0308-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/308, 26rpm, 16.2kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 26 rpm | Output Torque: 16.2 kgf·cm | Shaft Type: R-Type | |
| KGE-0350-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/350, 22.9rpm, 18.4kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 22.9 rpm | Output Torque: 18.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0452-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/452, 17.7rpm, 20kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 17.7 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type | |
| KGE-0615-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/615, 13rpm, 20kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 13 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type | |
| KGE-0687-KD3429P1-R | KGE-3429-P1 R-Type offset geared, 1/687, 11.6rpm, 20kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 11.6 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type |
GGM KGE-3429-P2 f-type offset parallel-shaft geared DC motor, DC 24V (9500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
GGM KGE-3429-P2 f-type offset parallel-shaft geared DC motor, DC 24V (9500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/22, 364rpm, 0.6kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 364 rpm | Output Torque: 0.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0034-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/34, 235rpm, 1kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 235 rpm | Output Torque: 1 kgf·cm | Shaft Type: F-Type | |
| KGE-0043-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/43, 186rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 186 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0050-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/50, 160rpm, 1.5kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 160 rpm | Output Torque: 1.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0062-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/62, 129rpm, 1.8kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 129 rpm | Output Torque: 1.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0068-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/68, 117.6rpm, 2kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 117.6 rpm | Output Torque: 2 kgf·cm | Shaft Type: F-Type | |
| KGE-0083-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/83, 96.4rpm, 2.4kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 96.4 rpm | Output Torque: 2.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0105-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/105, 76.2rpm, 3kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 76.2 rpm | Output Torque: 3 kgf·cm | Shaft Type: F-Type | |
| KGE-0116-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/116, 69rpm, 3.4kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 69 rpm | Output Torque: 3.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0162-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/162, 49.4rpm, 4.3kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 49.4 rpm | Output Torque: 4.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0182-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/182, 44rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 44 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0204-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/204, 39.2rpm, 5.4kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 39.2 rpm | Output Torque: 5.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0240-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/240, 33.3rpm, 6.3kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 33.3 rpm | Output Torque: 6.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0308-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/308, 26rpm, 8.1kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 26 rpm | Output Torque: 8.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0350-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/350, 22.9rpm, 9.2kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 22.9 rpm | Output Torque: 9.2 kgf·cm | Shaft Type: F-Type | |
| KGE-0452-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/452, 17.7rpm, 11.9kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 17.7 rpm | Output Torque: 11.9 kgf·cm | Shaft Type: F-Type | |
| KGE-0615-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/615, 13rpm, 16.1kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 13 rpm | Output Torque: 16.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0687-KD3429P2 | KGE-3429-P2 F-Type offset geared, 1/687, 11.6rpm, 18kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 11.6 rpm | Output Torque: 18 kgf·cm | Shaft Type: F-Type |
GGM KGE-3429-P2 r-type offset parallel-shaft geared DC motor, DC 24V (9500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
GGM KGE-3429-P2 r-type offset parallel-shaft geared DC motor, DC 24V (9500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/22, 364rpm, 0.6kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 364 rpm | Output Torque: 0.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0034-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/34, 235rpm, 1kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 235 rpm | Output Torque: 1 kgf·cm | Shaft Type: R-Type | |
| KGE-0043-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/43, 186rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 186 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0050-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/50, 160rpm, 1.5kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 160 rpm | Output Torque: 1.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0062-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/62, 129rpm, 1.8kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 129 rpm | Output Torque: 1.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0068-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/68, 117.6rpm, 2kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 117.6 rpm | Output Torque: 2 kgf·cm | Shaft Type: R-Type | |
| KGE-0083-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/83, 96.4rpm, 2.4kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 96.4 rpm | Output Torque: 2.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0105-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/105, 76.2rpm, 3kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 76.2 rpm | Output Torque: 3 kgf·cm | Shaft Type: R-Type | |
| KGE-0116-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/116, 69rpm, 3.4kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 69 rpm | Output Torque: 3.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0162-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/162, 49.4rpm, 4.3kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 49.4 rpm | Output Torque: 4.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0182-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/182, 44rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 44 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0204-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/204, 39.2rpm, 5.4kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 39.2 rpm | Output Torque: 5.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0240-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/240, 33.3rpm, 6.3kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 33.3 rpm | Output Torque: 6.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0308-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/308, 26rpm, 8.1kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 26 rpm | Output Torque: 8.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0350-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/350, 22.9rpm, 9.2kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 22.9 rpm | Output Torque: 9.2 kgf·cm | Shaft Type: R-Type | |
| KGE-0452-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/452, 17.7rpm, 11.9kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 17.7 rpm | Output Torque: 11.9 kgf·cm | Shaft Type: R-Type | |
| KGE-0615-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/615, 13rpm, 16.1kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 13 rpm | Output Torque: 16.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0687-KD3429P2-R | KGE-3429-P2 R-Type offset geared, 1/687, 11.6rpm, 18kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 11.6 rpm | Output Torque: 18 kgf·cm | Shaft Type: R-Type |
GGM KGE-3429-S1 f-type offset parallel-shaft geared DC motor, DC 12V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
GGM KGE-3429-S1 f-type offset parallel-shaft geared DC motor, DC 12V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/22, 205rpm, 0.6kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 205 rpm | Output Torque: 0.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0034-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/34, 132rpm, 1kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 132 rpm | Output Torque: 1 kgf·cm | Shaft Type: F-Type | |
| KGE-0043-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/43, 104.7rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 104.7 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0050-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/50, 90rpm, 1.5kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 90 rpm | Output Torque: 1.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0062-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/62, 72.6rpm, 1.8kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 72.6 rpm | Output Torque: 1.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0068-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/68, 66.2rpm, 2kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 66.2 rpm | Output Torque: 2 kgf·cm | Shaft Type: F-Type | |
| KGE-0083-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/83, 54.2rpm, 2.4kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 54.2 rpm | Output Torque: 2.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0105-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/105, 42.9rpm, 3kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 42.9 rpm | Output Torque: 3 kgf·cm | Shaft Type: F-Type | |
| KGE-0116-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/116, 38.8rpm, 3.4kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 38.8 rpm | Output Torque: 3.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0162-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/162, 27.8rpm, 4.3kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 27.8 rpm | Output Torque: 4.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0182-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/182, 24.7rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 24.7 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0204-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/204, 22rpm, 5.4kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 22 rpm | Output Torque: 5.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0240-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/240, 18.8rpm, 6.3kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 18.8 rpm | Output Torque: 6.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0308-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/308, 14.6rpm, 8.1kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 14.6 rpm | Output Torque: 8.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0350-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/350, 12.9rpm, 9.2kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 12.9 rpm | Output Torque: 9.2 kgf·cm | Shaft Type: F-Type | |
| KGE-0452-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/452, 10rpm, 11.9kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 10 rpm | Output Torque: 11.9 kgf·cm | Shaft Type: F-Type | |
| KGE-0615-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/615, 7.3rpm, 16.1kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 7.3 rpm | Output Torque: 16.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0687-KD3429S1 | KGE-3429-S1 F-Type offset geared, 1/687, 6.5rpm, 18kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 6.5 rpm | Output Torque: 18 kgf·cm | Shaft Type: F-Type |
GGM KGE-3429-S1 r-type offset parallel-shaft geared DC motor, DC 12V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
GGM KGE-3429-S1 r-type offset parallel-shaft geared DC motor, DC 12V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/22, 205rpm, 0.6kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 205 rpm | Output Torque: 0.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0034-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/34, 132rpm, 1kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 132 rpm | Output Torque: 1 kgf·cm | Shaft Type: R-Type | |
| KGE-0043-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/43, 104.7rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 104.7 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0050-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/50, 90rpm, 1.5kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 90 rpm | Output Torque: 1.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0062-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/62, 72.6rpm, 1.8kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 72.6 rpm | Output Torque: 1.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0068-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/68, 66.2rpm, 2kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 66.2 rpm | Output Torque: 2 kgf·cm | Shaft Type: R-Type | |
| KGE-0083-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/83, 54.2rpm, 2.4kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 54.2 rpm | Output Torque: 2.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0105-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/105, 42.9rpm, 3kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 42.9 rpm | Output Torque: 3 kgf·cm | Shaft Type: R-Type | |
| KGE-0116-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/116, 38.8rpm, 3.4kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 38.8 rpm | Output Torque: 3.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0162-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/162, 27.8rpm, 4.3kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 27.8 rpm | Output Torque: 4.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0182-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/182, 24.7rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 24.7 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0204-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/204, 22rpm, 5.4kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 22 rpm | Output Torque: 5.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0240-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/240, 18.8rpm, 6.3kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 18.8 rpm | Output Torque: 6.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0308-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/308, 14.6rpm, 8.1kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 14.6 rpm | Output Torque: 8.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0350-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/350, 12.9rpm, 9.2kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 12.9 rpm | Output Torque: 9.2 kgf·cm | Shaft Type: R-Type | |
| KGE-0452-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/452, 10rpm, 11.9kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 10 rpm | Output Torque: 11.9 kgf·cm | Shaft Type: R-Type | |
| KGE-0615-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/615, 7.3rpm, 16.1kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 7.3 rpm | Output Torque: 16.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0687-KD3429S1-R | KGE-3429-S1 R-Type offset geared, 1/687, 6.5rpm, 18kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 6.5 rpm | Output Torque: 18 kgf·cm | Shaft Type: R-Type |
GGM KGE-3429-S2 f-type offset parallel-shaft geared DC motor, DC 24V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
GGM KGE-3429-S2 f-type offset parallel-shaft geared DC motor, DC 24V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/22, 205rpm, 0.6kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 205 rpm | Output Torque: 0.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0034-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/34, 132rpm, 1kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 132 rpm | Output Torque: 1 kgf·cm | Shaft Type: F-Type | |
| KGE-0043-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/43, 104.7rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 104.7 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0050-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/50, 90rpm, 1.5kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 90 rpm | Output Torque: 1.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0062-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/62, 72.6rpm, 1.8kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 72.6 rpm | Output Torque: 1.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0068-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/68, 66.2rpm, 2kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 66.2 rpm | Output Torque: 2 kgf·cm | Shaft Type: F-Type | |
| KGE-0083-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/83, 54.2rpm, 2.4kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 54.2 rpm | Output Torque: 2.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0105-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/105, 42.9rpm, 3kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 42.9 rpm | Output Torque: 3 kgf·cm | Shaft Type: F-Type | |
| KGE-0116-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/116, 38.8rpm, 3.4kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 38.8 rpm | Output Torque: 3.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0162-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/162, 27.8rpm, 4.3kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 27.8 rpm | Output Torque: 4.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0182-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/182, 24.7rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 24.7 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0204-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/204, 22rpm, 5.4kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 22 rpm | Output Torque: 5.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0240-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/240, 18.8rpm, 6.3kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 18.8 rpm | Output Torque: 6.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0308-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/308, 14.6rpm, 8.1kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 14.6 rpm | Output Torque: 8.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0350-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/350, 12.9rpm, 9.2kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 12.9 rpm | Output Torque: 9.2 kgf·cm | Shaft Type: F-Type | |
| KGE-0452-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/452, 10rpm, 11.9kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 10 rpm | Output Torque: 11.9 kgf·cm | Shaft Type: F-Type | |
| KGE-0615-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/615, 7.3rpm, 16.1kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 7.3 rpm | Output Torque: 16.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0687-KD3429S2 | KGE-3429-S2 F-Type offset geared, 1/687, 6.5rpm, 18kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 6.5 rpm | Output Torque: 18 kgf·cm | Shaft Type: F-Type |
GGM KGE-3429-S2 r-type offset parallel-shaft geared DC motor, DC 24V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
GGM KGE-3429-S2 r-type offset parallel-shaft geared DC motor, DC 24V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/22, 205rpm, 0.6kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 205 rpm | Output Torque: 0.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0034-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/34, 132rpm, 1kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 132 rpm | Output Torque: 1 kgf·cm | Shaft Type: R-Type | |
| KGE-0043-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/43, 104.7rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 104.7 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0050-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/50, 90rpm, 1.5kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 90 rpm | Output Torque: 1.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0062-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/62, 72.6rpm, 1.8kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 72.6 rpm | Output Torque: 1.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0068-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/68, 66.2rpm, 2kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 66.2 rpm | Output Torque: 2 kgf·cm | Shaft Type: R-Type | |
| KGE-0083-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/83, 54.2rpm, 2.4kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 54.2 rpm | Output Torque: 2.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0105-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/105, 42.9rpm, 3kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 42.9 rpm | Output Torque: 3 kgf·cm | Shaft Type: R-Type | |
| KGE-0116-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/116, 38.8rpm, 3.4kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 38.8 rpm | Output Torque: 3.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0162-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/162, 27.8rpm, 4.3kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 27.8 rpm | Output Torque: 4.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0182-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/182, 24.7rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 24.7 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0204-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/204, 22rpm, 5.4kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 22 rpm | Output Torque: 5.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0240-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/240, 18.8rpm, 6.3kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 18.8 rpm | Output Torque: 6.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0308-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/308, 14.6rpm, 8.1kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 14.6 rpm | Output Torque: 8.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0350-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/350, 12.9rpm, 9.2kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 12.9 rpm | Output Torque: 9.2 kgf·cm | Shaft Type: R-Type | |
| KGE-0452-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/452, 10rpm, 11.9kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 10 rpm | Output Torque: 11.9 kgf·cm | Shaft Type: R-Type | |
| KGE-0615-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/615, 7.3rpm, 16.1kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 7.3 rpm | Output Torque: 16.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0687-KD3429S2-R | KGE-3429-S2 R-Type offset geared, 1/687, 6.5rpm, 18kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 6.5 rpm | Output Torque: 18 kgf·cm | Shaft Type: R-Type |
GGM KGE-3429-T1 f-type offset parallel-shaft geared DC motor, DC 12V (7500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
GGM KGE-3429-T1 f-type offset parallel-shaft geared DC motor, DC 12V (7500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/22, 295rpm, 0.6kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 295 rpm | Output Torque: 0.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0034-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/34, 191rpm, 1kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 191 rpm | Output Torque: 1 kgf·cm | Shaft Type: F-Type | |
| KGE-0043-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/43, 151rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 151 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0050-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/50, 130rpm, 1.5kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 130 rpm | Output Torque: 1.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0062-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/62, 105rpm, 1.8kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 105 rpm | Output Torque: 1.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0068-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/68, 95.5rpm, 2kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 95.5 rpm | Output Torque: 2 kgf·cm | Shaft Type: F-Type | |
| KGE-0083-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/83, 78.3rpm, 2.4kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 78.3 rpm | Output Torque: 2.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0105-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/105, 62rpm, 3kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 62 rpm | Output Torque: 3 kgf·cm | Shaft Type: F-Type | |
| KGE-0116-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/116, 56rpm, 3.4kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 56 rpm | Output Torque: 3.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0162-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/162, 40rpm, 4.3kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 40 rpm | Output Torque: 4.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0182-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/182, 35.7rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 35.7 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0204-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/204, 31.8rpm, 5.4kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 31.8 rpm | Output Torque: 5.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0240-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/240, 27.1rpm, 6.3kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 27.1 rpm | Output Torque: 6.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0308-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/308, 21.1rpm, 8.1kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 21.1 rpm | Output Torque: 8.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0350-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/350, 18.6rpm, 9.2kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 18.6 rpm | Output Torque: 9.2 kgf·cm | Shaft Type: F-Type | |
| KGE-0452-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/452, 14.4rpm, 11.9kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 14.4 rpm | Output Torque: 11.9 kgf·cm | Shaft Type: F-Type | |
| KGE-0615-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/615, 10.5rpm, 16.1kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 10.5 rpm | Output Torque: 16.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0687-KD3429T1 | KGE-3429-T1 F-Type offset geared, 1/687, 9.5rpm, 18kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 9.5 rpm | Output Torque: 18 kgf·cm | Shaft Type: F-Type |
GGM KGE-3429-T1 r-type offset parallel-shaft geared DC motor, DC 12V (7500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
GGM KGE-3429-T1 r-type offset parallel-shaft geared DC motor, DC 12V (7500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/22, 295rpm, 0.6kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 295 rpm | Output Torque: 0.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0034-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/34, 191rpm, 1kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 191 rpm | Output Torque: 1 kgf·cm | Shaft Type: R-Type | |
| KGE-0043-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/43, 151rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 151 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0050-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/50, 130rpm, 1.5kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 130 rpm | Output Torque: 1.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0062-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/62, 105rpm, 1.8kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 105 rpm | Output Torque: 1.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0068-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/68, 95.5rpm, 2kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 95.5 rpm | Output Torque: 2 kgf·cm | Shaft Type: R-Type | |
| KGE-0083-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/83, 78.3rpm, 2.4kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 78.3 rpm | Output Torque: 2.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0105-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/105, 62rpm, 3kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 62 rpm | Output Torque: 3 kgf·cm | Shaft Type: R-Type | |
| KGE-0116-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/116, 56rpm, 3.4kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 56 rpm | Output Torque: 3.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0162-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/162, 40rpm, 4.3kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 40 rpm | Output Torque: 4.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0182-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/182, 35.7rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 35.7 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0204-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/204, 31.8rpm, 5.4kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 31.8 rpm | Output Torque: 5.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0240-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/240, 27.1rpm, 6.3kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 27.1 rpm | Output Torque: 6.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0308-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/308, 21.1rpm, 8.1kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 21.1 rpm | Output Torque: 8.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0350-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/350, 18.6rpm, 9.2kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 18.6 rpm | Output Torque: 9.2 kgf·cm | Shaft Type: R-Type | |
| KGE-0452-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/452, 14.4rpm, 11.9kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 14.4 rpm | Output Torque: 11.9 kgf·cm | Shaft Type: R-Type | |
| KGE-0615-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/615, 10.5rpm, 16.1kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 10.5 rpm | Output Torque: 16.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0687-KD3429T1-R | KGE-3429-T1 R-Type offset geared, 1/687, 9.5rpm, 18kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 9.5 rpm | Output Torque: 18 kgf·cm | Shaft Type: R-Type |
GGM KGE-3429-T2 f-type offset parallel-shaft geared DC motor, DC 24V (7500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
GGM KGE-3429-T2 f-type offset parallel-shaft geared DC motor, DC 24V (7500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/22, 295rpm, 0.6kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 295 rpm | Output Torque: 0.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0034-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/34, 191rpm, 1kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 191 rpm | Output Torque: 1 kgf·cm | Shaft Type: F-Type | |
| KGE-0043-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/43, 151rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 151 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0050-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/50, 130rpm, 1.5kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 130 rpm | Output Torque: 1.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0062-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/62, 105rpm, 1.8kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 105 rpm | Output Torque: 1.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0068-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/68, 95.5rpm, 2kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 95.5 rpm | Output Torque: 2 kgf·cm | Shaft Type: F-Type | |
| KGE-0083-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/83, 78.3rpm, 2.4kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 78.3 rpm | Output Torque: 2.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0105-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/105, 62rpm, 3kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 62 rpm | Output Torque: 3 kgf·cm | Shaft Type: F-Type | |
| KGE-0116-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/116, 56rpm, 3.4kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 56 rpm | Output Torque: 3.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0162-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/162, 40rpm, 4.3kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 40 rpm | Output Torque: 4.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0182-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/182, 35.7rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 35.7 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0204-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/204, 31.8rpm, 5.4kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 31.8 rpm | Output Torque: 5.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0240-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/240, 27.1rpm, 6.3kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 27.1 rpm | Output Torque: 6.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0308-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/308, 21.1rpm, 8.1kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 21.1 rpm | Output Torque: 8.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0350-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/350, 18.6rpm, 9.2kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 18.6 rpm | Output Torque: 9.2 kgf·cm | Shaft Type: F-Type | |
| KGE-0452-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/452, 14.4rpm, 11.9kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 14.4 rpm | Output Torque: 11.9 kgf·cm | Shaft Type: F-Type | |
| KGE-0615-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/615, 10.5rpm, 16.1kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 10.5 rpm | Output Torque: 16.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0687-KD3429T2 | KGE-3429-T2 F-Type offset geared, 1/687, 9.5rpm, 18kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 9.5 rpm | Output Torque: 18 kgf·cm | Shaft Type: F-Type |
GGM KGE-3429-T2 r-type offset parallel-shaft geared DC motor, DC 24V (7500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
GGM KGE-3429-T2 r-type offset parallel-shaft geared DC motor, DC 24V (7500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/22, 295rpm, 0.6kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 295 rpm | Output Torque: 0.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0034-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/34, 191rpm, 1kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 191 rpm | Output Torque: 1 kgf·cm | Shaft Type: R-Type | |
| KGE-0043-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/43, 151rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 151 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0050-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/50, 130rpm, 1.5kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 130 rpm | Output Torque: 1.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0062-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/62, 105rpm, 1.8kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 105 rpm | Output Torque: 1.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0068-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/68, 95.5rpm, 2kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 95.5 rpm | Output Torque: 2 kgf·cm | Shaft Type: R-Type | |
| KGE-0083-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/83, 78.3rpm, 2.4kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 78.3 rpm | Output Torque: 2.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0105-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/105, 62rpm, 3kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 62 rpm | Output Torque: 3 kgf·cm | Shaft Type: R-Type | |
| KGE-0116-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/116, 56rpm, 3.4kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 56 rpm | Output Torque: 3.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0162-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/162, 40rpm, 4.3kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 40 rpm | Output Torque: 4.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0182-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/182, 35.7rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 35.7 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0204-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/204, 31.8rpm, 5.4kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 31.8 rpm | Output Torque: 5.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0240-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/240, 27.1rpm, 6.3kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 27.1 rpm | Output Torque: 6.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0308-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/308, 21.1rpm, 8.1kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 21.1 rpm | Output Torque: 8.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0350-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/350, 18.6rpm, 9.2kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 18.6 rpm | Output Torque: 9.2 kgf·cm | Shaft Type: R-Type | |
| KGE-0452-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/452, 14.4rpm, 11.9kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 14.4 rpm | Output Torque: 11.9 kgf·cm | Shaft Type: R-Type | |
| KGE-0615-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/615, 10.5rpm, 16.1kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 10.5 rpm | Output Torque: 16.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0687-KD3429T2-R | KGE-3429-T2 R-Type offset geared, 1/687, 9.5rpm, 18kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 9.5 rpm | Output Torque: 18 kgf·cm | Shaft Type: R-Type |
![[GGM] — KGE-3448-P1 F-Type Offset Geared DC Motor (DC 12V, 9000rpm base, 18 ratios 1/22-1/687)](https://img.prosourcemro.com/2026/06/0605-6-300x300.png)
GGM KGE-3448-P1 f-type offset parallel-shaft geared DC motor, DC 12V (9000 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
GGM KGE-3448-P1 f-type offset parallel-shaft geared DC motor, DC 12V (9000 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/22, 364rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 364 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0034-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/34, 235rpm, 2kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 235 rpm | Output Torque: 2 kgf·cm | Shaft Type: F-Type | |
| KGE-0043-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/43, 186rpm, 2.5kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 186 rpm | Output Torque: 2.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0050-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/50, 160rpm, 2.9kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 160 rpm | Output Torque: 2.9 kgf·cm | Shaft Type: F-Type | |
| KGE-0062-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/62, 129rpm, 3.6kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 129 rpm | Output Torque: 3.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0068-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/68, 117.6rpm, 4kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 117.6 rpm | Output Torque: 4 kgf·cm | Shaft Type: F-Type | |
| KGE-0083-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/83, 96.4rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 96.4 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0105-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/105, 76.2rpm, 6.1kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 76.2 rpm | Output Torque: 6.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0116-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/116, 69rpm, 6.8kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 69 rpm | Output Torque: 6.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0162-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/162, 49.4rpm, 8.5kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 49.4 rpm | Output Torque: 8.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0182-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/182, 44rpm, 9.6kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 44 rpm | Output Torque: 9.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0204-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/204, 39.2rpm, 10.7kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 39.2 rpm | Output Torque: 10.7 kgf·cm | Shaft Type: F-Type | |
| KGE-0240-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/240, 33.3rpm, 12.6kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 33.3 rpm | Output Torque: 12.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0308-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/308, 26rpm, 16.2kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 26 rpm | Output Torque: 16.2 kgf·cm | Shaft Type: F-Type | |
| KGE-0350-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/350, 22.9rpm, 18.4kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 22.9 rpm | Output Torque: 18.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0452-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/452, 17.7rpm, 20kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 17.7 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type | |
| KGE-0615-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/615, 13rpm, 20kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 13 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type | |
| KGE-0687-KD3448P1 | KGE-3448-P1 F-Type offset geared, 1/687, 11.6rpm, 20kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 11.6 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type |
GGM KGE-3448-P1 r-type offset parallel-shaft geared DC motor, DC 12V (9000 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
GGM KGE-3448-P1 r-type offset parallel-shaft geared DC motor, DC 12V (9000 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/22, 364rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 364 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0034-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/34, 235rpm, 2kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 235 rpm | Output Torque: 2 kgf·cm | Shaft Type: R-Type | |
| KGE-0043-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/43, 186rpm, 2.5kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 186 rpm | Output Torque: 2.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0050-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/50, 160rpm, 2.9kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 160 rpm | Output Torque: 2.9 kgf·cm | Shaft Type: R-Type | |
| KGE-0062-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/62, 129rpm, 3.6kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 129 rpm | Output Torque: 3.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0068-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/68, 117.6rpm, 4kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 117.6 rpm | Output Torque: 4 kgf·cm | Shaft Type: R-Type | |
| KGE-0083-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/83, 96.4rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 96.4 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0105-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/105, 76.2rpm, 6.1kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 76.2 rpm | Output Torque: 6.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0116-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/116, 69rpm, 6.8kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 69 rpm | Output Torque: 6.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0162-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/162, 49.4rpm, 8.5kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 49.4 rpm | Output Torque: 8.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0182-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/182, 44rpm, 9.6kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 44 rpm | Output Torque: 9.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0204-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/204, 39.2rpm, 10.7kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 39.2 rpm | Output Torque: 10.7 kgf·cm | Shaft Type: R-Type | |
| KGE-0240-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/240, 33.3rpm, 12.6kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 33.3 rpm | Output Torque: 12.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0308-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/308, 26rpm, 16.2kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 26 rpm | Output Torque: 16.2 kgf·cm | Shaft Type: R-Type | |
| KGE-0350-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/350, 22.9rpm, 18.4kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 22.9 rpm | Output Torque: 18.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0452-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/452, 17.7rpm, 20kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 17.7 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type | |
| KGE-0615-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/615, 13rpm, 20kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 13 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type | |
| KGE-0687-KD3448P1-R | KGE-3448-P1 R-Type offset geared, 1/687, 11.6rpm, 20kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 11.6 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type |
GGM KGE-3448-P2 f-type offset parallel-shaft geared DC motor, DC 24V (9000 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
GGM KGE-3448-P2 f-type offset parallel-shaft geared DC motor, DC 24V (9000 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/22, 364rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 364 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0034-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/34, 235rpm, 2kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 235 rpm | Output Torque: 2 kgf·cm | Shaft Type: F-Type | |
| KGE-0043-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/43, 186rpm, 2.5kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 186 rpm | Output Torque: 2.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0050-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/50, 160rpm, 2.9kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 160 rpm | Output Torque: 2.9 kgf·cm | Shaft Type: F-Type | |
| KGE-0062-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/62, 129rpm, 3.6kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 129 rpm | Output Torque: 3.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0068-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/68, 117.6rpm, 4kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 117.6 rpm | Output Torque: 4 kgf·cm | Shaft Type: F-Type | |
| KGE-0083-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/83, 96.4rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 96.4 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0105-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/105, 76.2rpm, 6.1kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 76.2 rpm | Output Torque: 6.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0116-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/116, 69rpm, 6.8kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 69 rpm | Output Torque: 6.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0162-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/162, 49.4rpm, 8.5kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 49.4 rpm | Output Torque: 8.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0182-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/182, 44rpm, 9.6kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 44 rpm | Output Torque: 9.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0204-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/204, 39.2rpm, 10.7kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 39.2 rpm | Output Torque: 10.7 kgf·cm | Shaft Type: F-Type | |
| KGE-0240-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/240, 33.3rpm, 12.6kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 33.3 rpm | Output Torque: 12.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0308-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/308, 26rpm, 16.2kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 26 rpm | Output Torque: 16.2 kgf·cm | Shaft Type: F-Type | |
| KGE-0350-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/350, 22.9rpm, 18.4kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 22.9 rpm | Output Torque: 18.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0452-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/452, 17.7rpm, 20kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 17.7 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type | |
| KGE-0615-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/615, 13rpm, 20kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 13 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type | |
| KGE-0687-KD3448P2 | KGE-3448-P2 F-Type offset geared, 1/687, 11.6rpm, 20kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 11.6 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type |
GGM KGE-3448-P2 r-type offset parallel-shaft geared DC motor, DC 24V (9000 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
GGM KGE-3448-P2 r-type offset parallel-shaft geared DC motor, DC 24V (9000 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/22, 364rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 364 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0034-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/34, 235rpm, 2kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 235 rpm | Output Torque: 2 kgf·cm | Shaft Type: R-Type | |
| KGE-0043-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/43, 186rpm, 2.5kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 186 rpm | Output Torque: 2.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0050-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/50, 160rpm, 2.9kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 160 rpm | Output Torque: 2.9 kgf·cm | Shaft Type: R-Type | |
| KGE-0062-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/62, 129rpm, 3.6kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 129 rpm | Output Torque: 3.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0068-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/68, 117.6rpm, 4kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 117.6 rpm | Output Torque: 4 kgf·cm | Shaft Type: R-Type | |
| KGE-0083-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/83, 96.4rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 96.4 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0105-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/105, 76.2rpm, 6.1kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 76.2 rpm | Output Torque: 6.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0116-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/116, 69rpm, 6.8kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 69 rpm | Output Torque: 6.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0162-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/162, 49.4rpm, 8.5kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 49.4 rpm | Output Torque: 8.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0182-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/182, 44rpm, 9.6kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 44 rpm | Output Torque: 9.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0204-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/204, 39.2rpm, 10.7kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 39.2 rpm | Output Torque: 10.7 kgf·cm | Shaft Type: R-Type | |
| KGE-0240-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/240, 33.3rpm, 12.6kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 33.3 rpm | Output Torque: 12.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0308-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/308, 26rpm, 16.2kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 26 rpm | Output Torque: 16.2 kgf·cm | Shaft Type: R-Type | |
| KGE-0350-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/350, 22.9rpm, 18.4kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 22.9 rpm | Output Torque: 18.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0452-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/452, 17.7rpm, 20kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 17.7 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type | |
| KGE-0615-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/615, 13rpm, 20kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 13 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type | |
| KGE-0687-KD3448P2-R | KGE-3448-P2 R-Type offset geared, 1/687, 11.6rpm, 20kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 11.6 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type |
GGM KGE-3448-S1 f-type offset parallel-shaft geared DC motor, DC 12V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
GGM KGE-3448-S1 f-type offset parallel-shaft geared DC motor, DC 12V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/22, 205rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 205 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0034-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/34, 132rpm, 2kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 132 rpm | Output Torque: 2 kgf·cm | Shaft Type: F-Type | |
| KGE-0043-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/43, 104.7rpm, 2.5kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 104.7 rpm | Output Torque: 2.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0050-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/50, 90rpm, 2.9kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 90 rpm | Output Torque: 2.9 kgf·cm | Shaft Type: F-Type | |
| KGE-0062-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/62, 72.6rpm, 3.6kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 72.6 rpm | Output Torque: 3.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0068-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/68, 66.2rpm, 4kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 66.2 rpm | Output Torque: 4 kgf·cm | Shaft Type: F-Type | |
| KGE-0083-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/83, 54.2rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 54.2 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0105-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/105, 42.9rpm, 6.1kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 42.9 rpm | Output Torque: 6.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0116-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/116, 38.8rpm, 6.8kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 38.8 rpm | Output Torque: 6.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0162-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/162, 27.8rpm, 8.5kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 27.8 rpm | Output Torque: 8.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0182-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/182, 24.7rpm, 9.6kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 24.7 rpm | Output Torque: 9.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0204-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/204, 22rpm, 10.7kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 22 rpm | Output Torque: 10.7 kgf·cm | Shaft Type: F-Type | |
| KGE-0240-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/240, 18.8rpm, 12.6kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 18.8 rpm | Output Torque: 12.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0308-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/308, 14.6rpm, 16.2kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 14.6 rpm | Output Torque: 16.2 kgf·cm | Shaft Type: F-Type | |
| KGE-0350-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/350, 12.9rpm, 18.4kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 12.9 rpm | Output Torque: 18.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0452-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/452, 10rpm, 20kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 10 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type | |
| KGE-0615-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/615, 7.3rpm, 20kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 7.3 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type | |
| KGE-0687-KD3448S1 | KGE-3448-S1 F-Type offset geared, 1/687, 6.5rpm, 20kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 6.5 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type |
GGM KGE-3448-S1 r-type offset parallel-shaft geared DC motor, DC 12V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
GGM KGE-3448-S1 r-type offset parallel-shaft geared DC motor, DC 12V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/22, 205rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 205 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0034-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/34, 132rpm, 2kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 132 rpm | Output Torque: 2 kgf·cm | Shaft Type: R-Type | |
| KGE-0043-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/43, 104.7rpm, 2.5kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 104.7 rpm | Output Torque: 2.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0050-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/50, 90rpm, 2.9kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 90 rpm | Output Torque: 2.9 kgf·cm | Shaft Type: R-Type | |
| KGE-0062-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/62, 72.6rpm, 3.6kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 72.6 rpm | Output Torque: 3.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0068-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/68, 66.2rpm, 4kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 66.2 rpm | Output Torque: 4 kgf·cm | Shaft Type: R-Type | |
| KGE-0083-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/83, 54.2rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 54.2 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0105-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/105, 42.9rpm, 6.1kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 42.9 rpm | Output Torque: 6.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0116-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/116, 38.8rpm, 6.8kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 38.8 rpm | Output Torque: 6.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0162-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/162, 27.8rpm, 8.5kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 27.8 rpm | Output Torque: 8.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0182-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/182, 24.7rpm, 9.6kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 24.7 rpm | Output Torque: 9.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0204-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/204, 22rpm, 10.7kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 22 rpm | Output Torque: 10.7 kgf·cm | Shaft Type: R-Type | |
| KGE-0240-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/240, 18.8rpm, 12.6kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 18.8 rpm | Output Torque: 12.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0308-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/308, 14.6rpm, 16.2kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 14.6 rpm | Output Torque: 16.2 kgf·cm | Shaft Type: R-Type | |
| KGE-0350-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/350, 12.9rpm, 18.4kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 12.9 rpm | Output Torque: 18.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0452-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/452, 10rpm, 20kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 10 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type | |
| KGE-0615-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/615, 7.3rpm, 20kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 7.3 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type | |
| KGE-0687-KD3448S1-R | KGE-3448-S1 R-Type offset geared, 1/687, 6.5rpm, 20kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 6.5 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type |
GGM KGE-3448-S2 f-type offset parallel-shaft geared DC motor, DC 24V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
GGM KGE-3448-S2 f-type offset parallel-shaft geared DC motor, DC 24V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. F-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/22, 205rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 205 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: F-Type | |
| KGE-0034-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/34, 132rpm, 2kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 132 rpm | Output Torque: 2 kgf·cm | Shaft Type: F-Type | |
| KGE-0043-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/43, 104.7rpm, 2.5kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 104.7 rpm | Output Torque: 2.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0050-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/50, 90rpm, 2.9kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 90 rpm | Output Torque: 2.9 kgf·cm | Shaft Type: F-Type | |
| KGE-0062-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/62, 72.6rpm, 3.6kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 72.6 rpm | Output Torque: 3.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0068-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/68, 66.2rpm, 4kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 66.2 rpm | Output Torque: 4 kgf·cm | Shaft Type: F-Type | |
| KGE-0083-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/83, 54.2rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 54.2 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0105-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/105, 42.9rpm, 6.1kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 42.9 rpm | Output Torque: 6.1 kgf·cm | Shaft Type: F-Type | |
| KGE-0116-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/116, 38.8rpm, 6.8kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 38.8 rpm | Output Torque: 6.8 kgf·cm | Shaft Type: F-Type | |
| KGE-0162-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/162, 27.8rpm, 8.5kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 27.8 rpm | Output Torque: 8.5 kgf·cm | Shaft Type: F-Type | |
| KGE-0182-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/182, 24.7rpm, 9.6kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 24.7 rpm | Output Torque: 9.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0204-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/204, 22rpm, 10.7kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 22 rpm | Output Torque: 10.7 kgf·cm | Shaft Type: F-Type | |
| KGE-0240-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/240, 18.8rpm, 12.6kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 18.8 rpm | Output Torque: 12.6 kgf·cm | Shaft Type: F-Type | |
| KGE-0308-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/308, 14.6rpm, 16.2kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 14.6 rpm | Output Torque: 16.2 kgf·cm | Shaft Type: F-Type | |
| KGE-0350-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/350, 12.9rpm, 18.4kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 12.9 rpm | Output Torque: 18.4 kgf·cm | Shaft Type: F-Type | |
| KGE-0452-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/452, 10rpm, 20kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 10 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type | |
| KGE-0615-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/615, 7.3rpm, 20kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 7.3 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type | |
| KGE-0687-KD3448S2 | KGE-3448-S2 F-Type offset geared, 1/687, 6.5rpm, 20kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 6.5 rpm | Output Torque: 20 kgf·cm | Shaft Type: F-Type |
GGM KGE-3448-S2 r-type offset parallel-shaft geared DC motor, DC 24V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
GGM KGE-3448-S2 r-type offset parallel-shaft geared DC motor, DC 24V (5200 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 20 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing. R-Type shaft orientation (F-Type is standard).
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| KGE-0022-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/22, 205rpm, 1.3kgf·cm | GGM | Gear Ratio: 1/22 | Output Speed: 205 rpm | Output Torque: 1.3 kgf·cm | Shaft Type: R-Type | |
| KGE-0034-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/34, 132rpm, 2kgf·cm | GGM | Gear Ratio: 1/34 | Output Speed: 132 rpm | Output Torque: 2 kgf·cm | Shaft Type: R-Type | |
| KGE-0043-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/43, 104.7rpm, 2.5kgf·cm | GGM | Gear Ratio: 1/43 | Output Speed: 104.7 rpm | Output Torque: 2.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0050-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/50, 90rpm, 2.9kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 90 rpm | Output Torque: 2.9 kgf·cm | Shaft Type: R-Type | |
| KGE-0062-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/62, 72.6rpm, 3.6kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 72.6 rpm | Output Torque: 3.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0068-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/68, 66.2rpm, 4kgf·cm | GGM | Gear Ratio: 1/68 | Output Speed: 66.2 rpm | Output Torque: 4 kgf·cm | Shaft Type: R-Type | |
| KGE-0083-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/83, 54.2rpm, 4.8kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 54.2 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0105-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/105, 42.9rpm, 6.1kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 42.9 rpm | Output Torque: 6.1 kgf·cm | Shaft Type: R-Type | |
| KGE-0116-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/116, 38.8rpm, 6.8kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 38.8 rpm | Output Torque: 6.8 kgf·cm | Shaft Type: R-Type | |
| KGE-0162-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/162, 27.8rpm, 8.5kgf·cm | GGM | Gear Ratio: 1/162 | Output Speed: 27.8 rpm | Output Torque: 8.5 kgf·cm | Shaft Type: R-Type | |
| KGE-0182-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/182, 24.7rpm, 9.6kgf·cm | GGM | Gear Ratio: 1/182 | Output Speed: 24.7 rpm | Output Torque: 9.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0204-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/204, 22rpm, 10.7kgf·cm | GGM | Gear Ratio: 1/204 | Output Speed: 22 rpm | Output Torque: 10.7 kgf·cm | Shaft Type: R-Type | |
| KGE-0240-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/240, 18.8rpm, 12.6kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 18.8 rpm | Output Torque: 12.6 kgf·cm | Shaft Type: R-Type | |
| KGE-0308-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/308, 14.6rpm, 16.2kgf·cm | GGM | Gear Ratio: 1/308 | Output Speed: 14.6 rpm | Output Torque: 16.2 kgf·cm | Shaft Type: R-Type | |
| KGE-0350-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/350, 12.9rpm, 18.4kgf·cm | GGM | Gear Ratio: 1/350 | Output Speed: 12.9 rpm | Output Torque: 18.4 kgf·cm | Shaft Type: R-Type | |
| KGE-0452-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/452, 10rpm, 20kgf·cm | GGM | Gear Ratio: 1/452 | Output Speed: 10 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type | |
| KGE-0615-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/615, 7.3rpm, 20kgf·cm | GGM | Gear Ratio: 1/615 | Output Speed: 7.3 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type | |
| KGE-0687-KD3448S2-R | KGE-3448-S2 R-Type offset geared, 1/687, 6.5rpm, 20kgf·cm | GGM | Gear Ratio: 1/687 | Output Speed: 6.5 rpm | Output Torque: 20 kgf·cm | Shaft Type: R-Type |
