Valves
![[Yuken] — Feed Control Valve 2-stage (UCF2G)](https://img.prosourcemro.com/2026/05/002-42-300x247.png)
Feed Control Valves. Compact combination of flow control + check valve and deceleration valve for machine-tool rapid→feed switching by cam. Pressure/temperature compensated. Max. operating pressure: 14 MPa. 2-stage control type. Sizes 03/04. Internal / external (-E) drain.
Feed Control Valves. Compact combination of flow control + check valve and deceleration valve for machine-tool rapid→feed switching by cam. Pressure/temperature compensated. Max. operating pressure: 14 MPa. 2-stage control type. Sizes 03/04. Internal / external (-E) drain.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| UCF2G-03-4-10 | Feed Control Valve UCF2G-03-4-10, internal drain | Yuken | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 4 L/min | Max. Flow: 40 L/min | Adjustment Range 1st Stage: 0.1–4 L/min | Adjustment Range 2nd Stage: 0.05–4 L/min | Free Flow: 40 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 2.7 kg | Design No.: 10 | |
| UCF2G-03-4-E-10 | Feed Control Valve UCF2G-03-4-E-10, external drain | Yuken | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 4 L/min | Max. Flow: 40 L/min | Adjustment Range 1st Stage: 0.1–4 L/min | Adjustment Range 2nd Stage: 0.05–4 L/min | Free Flow: 40 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 2.7 kg | Design No.: 10 | |
| UCF2G-03-8-10 | Feed Control Valve UCF2G-03-8-10, internal drain | Yuken | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 8 L/min | Max. Flow: 40 L/min | Adjustment Range 1st Stage: 0.1–8 L/min | Adjustment Range 2nd Stage: 0.05–8 L/min | Free Flow: 40 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 2.7 kg | Design No.: 10 | |
| UCF2G-03-8-E-10 | Feed Control Valve UCF2G-03-8-E-10, external drain | Yuken | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 8 L/min | Max. Flow: 40 L/min | Adjustment Range 1st Stage: 0.1–8 L/min | Adjustment Range 2nd Stage: 0.05–8 L/min | Free Flow: 40 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 2.7 kg | Design No.: 10 | |
| UCF2G-04-30-30 | Feed Control Valve UCF2G-04-30-30, external drain | Yuken | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 04 | Adjustable Flow: 30 L/min | Max. Flow: 80 (40) L/min | Adjustment Range 1st Stage: 0.1–22 L/min | Adjustment Range 2nd Stage: 0.1–17 L/min | Free Flow: 80 L/min | Drain: External | Max. Operating Pressure: 14 MPa | Mass: 9.2 kg | Design No.: 30 |
![[Yuken] — Flow Control and Check Valve (FCG)](https://img.prosourcemro.com/2026/05/002-37-276x300.png)
Flow Control Valves · Flow Control and Check Valves. Max. operating pressure: 14 MPa (size 01) / 21 MPa (02–10). Max. adjustable flow: 4/8 (01) / 30 (02) / 125 (03) / 250 (06) / 500 (10) L/min. Digital scale (except size 01). Pressure-compensated piston opening adjustment (-N) available. Built-in check valve for free reverse flow.
Flow Control Valves · Flow Control and Check Valves. Max. operating pressure: 14 MPa (size 01) / 21 MPa (02–10). Max. adjustable flow: 4/8 (01) / 30 (02) / 125 (03) / 250 (06) / 500 (10) L/min. Digital scale (except size 01). Pressure-compensated piston opening adjustment (-N) available. Built-in check valve for free reverse flow.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| FCG-01-4-11 | Flow Control and Check Valve FCG-01-4 | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 4 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11 | |
| FCG-01-4-N-11 | Flow Control and Check Valve FCG-01-4-N | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 4 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11 | |
| FCG-01-8-11 | Flow Control and Check Valve FCG-01-8 | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 8 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11 | |
| FCG-01-8-N-11 | Flow Control and Check Valve FCG-01-8-N | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 8 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11 | |
| FCG-02-30-30 | Flow Control and Check Valve FCG-02-30 | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 02 | Max. Adjustable Flow: 30 L/min | Min. Adjustable Flow: 0.05 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 3.8 kg | Design No.: 30 | |
| FCG-02-30-N-30 | Flow Control and Check Valve FCG-02-30-N | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 02 | Max. Adjustable Flow: 30 L/min | Min. Adjustable Flow: 0.05 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 3.8 kg | Design No.: 30 | |
| FCG-03-125-30 | Flow Control and Check Valve FCG-03-125 | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 03 | Max. Adjustable Flow: 125 L/min | Min. Adjustable Flow: 0.2 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 7.9 kg | Design No.: 30 | |
| FCG-03-125-N-30 | Flow Control and Check Valve FCG-03-125-N | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 03 | Max. Adjustable Flow: 125 L/min | Min. Adjustable Flow: 0.2 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 7.9 kg | Design No.: 30 | |
| FCG-06-250-30 | Flow Control and Check Valve FCG-06-250 | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 06 | Max. Adjustable Flow: 250 L/min | Min. Adjustable Flow: 2 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 23 kg | Design No.: 30 | |
| FCG-06-250-N-30 | Flow Control and Check Valve FCG-06-250-N | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 06 | Max. Adjustable Flow: 250 L/min | Min. Adjustable Flow: 2 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 23 kg | Design No.: 30 | |
| FCG-10-500-30 | Flow Control and Check Valve FCG-10-500 | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 10 | Max. Adjustable Flow: 500 L/min | Min. Adjustable Flow: 4 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 52 kg | Design No.: 30 | |
| FCG-10-500-N-30 | Flow Control and Check Valve FCG-10-500-N | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 10 | Max. Adjustable Flow: 500 L/min | Min. Adjustable Flow: 4 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 52 kg | Design No.: 30 |
Flow Control Valves · Flow Control and Check Valves. Max. operating pressure: 14 MPa (size 01) / 21 MPa (02–10). Max. adjustable flow: 4/8 (01) / 30 (02) / 125 (03) / 250 (06) / 500 (10) L/min. Digital scale (except size 01). Pressure-compensated piston opening adjustment (-N) available.
Flow Control Valves · Flow Control and Check Valves. Max. operating pressure: 14 MPa (size 01) / 21 MPa (02–10). Max. adjustable flow: 4/8 (01) / 30 (02) / 125 (03) / 250 (06) / 500 (10) L/min. Digital scale (except size 01). Pressure-compensated piston opening adjustment (-N) available.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| FG-01-4-11 | Flow Control Valve FG-01-4 | Yuken | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 4 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11 | |
| FG-01-4-N-11 | Flow Control Valve FG-01-4-N | Yuken | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 4 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11 | |
| FG-01-8-11 | Flow Control Valve FG-01-8 | Yuken | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 8 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11 | |
| FG-01-8-N-11 | Flow Control Valve FG-01-8-N | Yuken | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 8 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11 | |
| FG-02-30-30 | Flow Control Valve FG-02-30 | Yuken | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 02 | Max. Adjustable Flow: 30 L/min | Min. Adjustable Flow: 0.05 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 3.8 kg | Design No.: 30 | |
| FG-02-30-N-30 | Flow Control Valve FG-02-30-N | Yuken | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 02 | Max. Adjustable Flow: 30 L/min | Min. Adjustable Flow: 0.05 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 3.8 kg | Design No.: 30 | |
| FG-03-125-30 | Flow Control Valve FG-03-125 | Yuken | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 03 | Max. Adjustable Flow: 125 L/min | Min. Adjustable Flow: 0.2 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 7.9 kg | Design No.: 30 | |
| FG-03-125-N-30 | Flow Control Valve FG-03-125-N | Yuken | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 03 | Max. Adjustable Flow: 125 L/min | Min. Adjustable Flow: 0.2 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 7.9 kg | Design No.: 30 | |
| FG-06-250-30 | Flow Control Valve FG-06-250 | Yuken | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 06 | Max. Adjustable Flow: 250 L/min | Min. Adjustable Flow: 2 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 23 kg | Design No.: 30 | |
| FG-06-250-N-30 | Flow Control Valve FG-06-250-N | Yuken | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 06 | Max. Adjustable Flow: 250 L/min | Min. Adjustable Flow: 2 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 23 kg | Design No.: 30 | |
| FG-10-500-30 | Flow Control Valve FG-10-500 | Yuken | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 10 | Max. Adjustable Flow: 500 L/min | Min. Adjustable Flow: 4 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 52 kg | Design No.: 30 | |
| FG-10-500-N-30 | Flow Control Valve FG-10-500-N | Yuken | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 10 | Max. Adjustable Flow: 500 L/min | Min. Adjustable Flow: 4 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 52 kg | Design No.: 30 |
![[Yuken] — H Type Pressure Control Valve (HG-03)](https://img.prosourcemro.com/2026/05/002-31-224x300.png)
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 50 L/min. H type, Sub-plate mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 4.0 kg.
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 50 L/min. H type, Sub-plate mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 4.0 kg.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| HG-03-L1-22 | H Type Pressure Control Valve HG-03-L1, Low Pressure Relief Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-M1-22 | H Type Pressure Control Valve HG-03-M1, Low Pressure Relief Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-L2-22 | H Type Pressure Control Valve HG-03-L2, Sequence Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-M2-22 | H Type Pressure Control Valve HG-03-M2, Sequence Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-N2-22 | H Type Pressure Control Valve HG-03-N2, Sequence Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-N2-P-22 | H Type Pressure Control Valve HG-03-N2-P, Sequence Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-A2-22 | H Type Pressure Control Valve HG-03-A2, Sequence Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-A2-P-22 | H Type Pressure Control Valve HG-03-A2-P, Sequence Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-B2-22 | H Type Pressure Control Valve HG-03-B2, Sequence Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-B2-P-22 | H Type Pressure Control Valve HG-03-B2-P, Sequence Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-C2-22 | H Type Pressure Control Valve HG-03-C2, Sequence Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-C2-P-22 | H Type Pressure Control Valve HG-03-C2-P, Sequence Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-L3-22 | H Type Pressure Control Valve HG-03-L3, Sequence Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-M3-22 | H Type Pressure Control Valve HG-03-M3, Sequence Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-N3-22 | H Type Pressure Control Valve HG-03-N3, Sequence Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-N3-P-22 | H Type Pressure Control Valve HG-03-N3-P, Sequence Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-A3-22 | H Type Pressure Control Valve HG-03-A3, Sequence Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-A3-P-22 | H Type Pressure Control Valve HG-03-A3-P, Sequence Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-B3-22 | H Type Pressure Control Valve HG-03-B3, Sequence Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-B3-P-22 | H Type Pressure Control Valve HG-03-B3-P, Sequence Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-C3-22 | H Type Pressure Control Valve HG-03-C3, Sequence Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-C3-P-22 | H Type Pressure Control Valve HG-03-C3-P, Sequence Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-L4-22 | H Type Pressure Control Valve HG-03-L4, Unloading Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-M4-22 | H Type Pressure Control Valve HG-03-M4, Unloading Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-N4-22 | H Type Pressure Control Valve HG-03-N4, Unloading Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-N4-P-22 | H Type Pressure Control Valve HG-03-N4-P, Unloading Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-A4-22 | H Type Pressure Control Valve HG-03-A4, Unloading Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-A4-P-22 | H Type Pressure Control Valve HG-03-A4-P, Unloading Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-B4-22 | H Type Pressure Control Valve HG-03-B4, Unloading Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-B4-P-22 | H Type Pressure Control Valve HG-03-B4-P, Unloading Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-C4-22 | H Type Pressure Control Valve HG-03-C4, Unloading Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 | |
| HG-03-C4-P-22 | H Type Pressure Control Valve HG-03-C4-P, Unloading Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.0 kg | Design No.: 22 |
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 125 L/min. H type, Sub-plate mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 6.1 kg.
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 125 L/min. H type, Sub-plate mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 6.1 kg.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| HG-06-L1-22 | H Type Pressure Control Valve HG-06-L1, Low Pressure Relief Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-M1-22 | H Type Pressure Control Valve HG-06-M1, Low Pressure Relief Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-L2-22 | H Type Pressure Control Valve HG-06-L2, Sequence Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-M2-22 | H Type Pressure Control Valve HG-06-M2, Sequence Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-N2-22 | H Type Pressure Control Valve HG-06-N2, Sequence Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-N2-P-22 | H Type Pressure Control Valve HG-06-N2-P, Sequence Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-A2-22 | H Type Pressure Control Valve HG-06-A2, Sequence Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-A2-P-22 | H Type Pressure Control Valve HG-06-A2-P, Sequence Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-B2-22 | H Type Pressure Control Valve HG-06-B2, Sequence Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-B2-P-22 | H Type Pressure Control Valve HG-06-B2-P, Sequence Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-C2-22 | H Type Pressure Control Valve HG-06-C2, Sequence Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-C2-P-22 | H Type Pressure Control Valve HG-06-C2-P, Sequence Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-L3-22 | H Type Pressure Control Valve HG-06-L3, Sequence Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-M3-22 | H Type Pressure Control Valve HG-06-M3, Sequence Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-N3-22 | H Type Pressure Control Valve HG-06-N3, Sequence Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-N3-P-22 | H Type Pressure Control Valve HG-06-N3-P, Sequence Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-A3-22 | H Type Pressure Control Valve HG-06-A3, Sequence Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-A3-P-22 | H Type Pressure Control Valve HG-06-A3-P, Sequence Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-B3-22 | H Type Pressure Control Valve HG-06-B3, Sequence Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-B3-P-22 | H Type Pressure Control Valve HG-06-B3-P, Sequence Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-C3-22 | H Type Pressure Control Valve HG-06-C3, Sequence Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-C3-P-22 | H Type Pressure Control Valve HG-06-C3-P, Sequence Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-L4-22 | H Type Pressure Control Valve HG-06-L4, Unloading Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-M4-22 | H Type Pressure Control Valve HG-06-M4, Unloading Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-N4-22 | H Type Pressure Control Valve HG-06-N4, Unloading Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-N4-P-22 | H Type Pressure Control Valve HG-06-N4-P, Unloading Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-A4-22 | H Type Pressure Control Valve HG-06-A4, Unloading Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-A4-P-22 | H Type Pressure Control Valve HG-06-A4-P, Unloading Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-B4-22 | H Type Pressure Control Valve HG-06-B4, Unloading Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-B4-P-22 | H Type Pressure Control Valve HG-06-B4-P, Unloading Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-C4-22 | H Type Pressure Control Valve HG-06-C4, Unloading Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 | |
| HG-06-C4-P-22 | H Type Pressure Control Valve HG-06-C4-P, Unloading Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22 |
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 250 L/min. H type, Sub-plate mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 11.0 kg.
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 250 L/min. H type, Sub-plate mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 11.0 kg.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| HG-10-L1-22 | H Type Pressure Control Valve HG-10-L1, Low Pressure Relief Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-M1-22 | H Type Pressure Control Valve HG-10-M1, Low Pressure Relief Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-L2-22 | H Type Pressure Control Valve HG-10-L2, Sequence Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-M2-22 | H Type Pressure Control Valve HG-10-M2, Sequence Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-N2-22 | H Type Pressure Control Valve HG-10-N2, Sequence Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-N2-P-22 | H Type Pressure Control Valve HG-10-N2-P, Sequence Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-A2-22 | H Type Pressure Control Valve HG-10-A2, Sequence Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-A2-P-22 | H Type Pressure Control Valve HG-10-A2-P, Sequence Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-B2-22 | H Type Pressure Control Valve HG-10-B2, Sequence Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-B2-P-22 | H Type Pressure Control Valve HG-10-B2-P, Sequence Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-C2-22 | H Type Pressure Control Valve HG-10-C2, Sequence Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-C2-P-22 | H Type Pressure Control Valve HG-10-C2-P, Sequence Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-L3-22 | H Type Pressure Control Valve HG-10-L3, Sequence Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-M3-22 | H Type Pressure Control Valve HG-10-M3, Sequence Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-N3-22 | H Type Pressure Control Valve HG-10-N3, Sequence Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-N3-P-22 | H Type Pressure Control Valve HG-10-N3-P, Sequence Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-A3-22 | H Type Pressure Control Valve HG-10-A3, Sequence Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-A3-P-22 | H Type Pressure Control Valve HG-10-A3-P, Sequence Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-B3-22 | H Type Pressure Control Valve HG-10-B3, Sequence Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-B3-P-22 | H Type Pressure Control Valve HG-10-B3-P, Sequence Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-C3-22 | H Type Pressure Control Valve HG-10-C3, Sequence Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-C3-P-22 | H Type Pressure Control Valve HG-10-C3-P, Sequence Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-L4-22 | H Type Pressure Control Valve HG-10-L4, Unloading Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-M4-22 | H Type Pressure Control Valve HG-10-M4, Unloading Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-N4-22 | H Type Pressure Control Valve HG-10-N4, Unloading Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-N4-P-22 | H Type Pressure Control Valve HG-10-N4-P, Unloading Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-A4-22 | H Type Pressure Control Valve HG-10-A4, Unloading Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-A4-P-22 | H Type Pressure Control Valve HG-10-A4-P, Unloading Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-B4-22 | H Type Pressure Control Valve HG-10-B4, Unloading Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-B4-P-22 | H Type Pressure Control Valve HG-10-B4-P, Unloading Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-C4-22 | H Type Pressure Control Valve HG-10-C4, Unloading Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 | |
| HG-10-C4-P-22 | H Type Pressure Control Valve HG-10-C4-P, Unloading Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 11.0 kg | Design No.: 22 |
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 50 L/min. H type, Threaded mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 3.7 kg.
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 50 L/min. H type, Threaded mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 3.7 kg.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| HT-03-L1-22 | H Type Pressure Control Valve HT-03-L1, Low Pressure Relief Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-M1-22 | H Type Pressure Control Valve HT-03-M1, Low Pressure Relief Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-L2-22 | H Type Pressure Control Valve HT-03-L2, Sequence Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-M2-22 | H Type Pressure Control Valve HT-03-M2, Sequence Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-N2-22 | H Type Pressure Control Valve HT-03-N2, Sequence Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-N2-P-22 | H Type Pressure Control Valve HT-03-N2-P, Sequence Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-A2-22 | H Type Pressure Control Valve HT-03-A2, Sequence Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-A2-P-22 | H Type Pressure Control Valve HT-03-A2-P, Sequence Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-B2-22 | H Type Pressure Control Valve HT-03-B2, Sequence Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-B2-P-22 | H Type Pressure Control Valve HT-03-B2-P, Sequence Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-C2-22 | H Type Pressure Control Valve HT-03-C2, Sequence Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-C2-P-22 | H Type Pressure Control Valve HT-03-C2-P, Sequence Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-L3-22 | H Type Pressure Control Valve HT-03-L3, Sequence Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-M3-22 | H Type Pressure Control Valve HT-03-M3, Sequence Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-N3-22 | H Type Pressure Control Valve HT-03-N3, Sequence Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-N3-P-22 | H Type Pressure Control Valve HT-03-N3-P, Sequence Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-A3-22 | H Type Pressure Control Valve HT-03-A3, Sequence Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-A3-P-22 | H Type Pressure Control Valve HT-03-A3-P, Sequence Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-B3-22 | H Type Pressure Control Valve HT-03-B3, Sequence Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-B3-P-22 | H Type Pressure Control Valve HT-03-B3-P, Sequence Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-C3-22 | H Type Pressure Control Valve HT-03-C3, Sequence Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-C3-P-22 | H Type Pressure Control Valve HT-03-C3-P, Sequence Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-L4-22 | H Type Pressure Control Valve HT-03-L4, Unloading Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-M4-22 | H Type Pressure Control Valve HT-03-M4, Unloading Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-N4-22 | H Type Pressure Control Valve HT-03-N4, Unloading Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-N4-P-22 | H Type Pressure Control Valve HT-03-N4-P, Unloading Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-A4-22 | H Type Pressure Control Valve HT-03-A4, Unloading Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-A4-P-22 | H Type Pressure Control Valve HT-03-A4-P, Unloading Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-B4-22 | H Type Pressure Control Valve HT-03-B4, Unloading Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-B4-P-22 | H Type Pressure Control Valve HT-03-B4-P, Unloading Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-C4-22 | H Type Pressure Control Valve HT-03-C4, Unloading Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 | |
| HT-03-C4-P-22 | H Type Pressure Control Valve HT-03-C4-P, Unloading Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 3.7 kg | Design No.: 22 |
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 125 L/min. H type, Threaded mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 6.2 kg.
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 125 L/min. H type, Threaded mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 6.2 kg.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| HT-06-L1-22 | H Type Pressure Control Valve HT-06-L1, Low Pressure Relief Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-M1-22 | H Type Pressure Control Valve HT-06-M1, Low Pressure Relief Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-L2-22 | H Type Pressure Control Valve HT-06-L2, Sequence Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-M2-22 | H Type Pressure Control Valve HT-06-M2, Sequence Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-N2-22 | H Type Pressure Control Valve HT-06-N2, Sequence Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-N2-P-22 | H Type Pressure Control Valve HT-06-N2-P, Sequence Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-A2-22 | H Type Pressure Control Valve HT-06-A2, Sequence Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-A2-P-22 | H Type Pressure Control Valve HT-06-A2-P, Sequence Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-B2-22 | H Type Pressure Control Valve HT-06-B2, Sequence Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-B2-P-22 | H Type Pressure Control Valve HT-06-B2-P, Sequence Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-C2-22 | H Type Pressure Control Valve HT-06-C2, Sequence Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-C2-P-22 | H Type Pressure Control Valve HT-06-C2-P, Sequence Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-L3-22 | H Type Pressure Control Valve HT-06-L3, Sequence Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-M3-22 | H Type Pressure Control Valve HT-06-M3, Sequence Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-N3-22 | H Type Pressure Control Valve HT-06-N3, Sequence Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-N3-P-22 | H Type Pressure Control Valve HT-06-N3-P, Sequence Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-A3-22 | H Type Pressure Control Valve HT-06-A3, Sequence Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-A3-P-22 | H Type Pressure Control Valve HT-06-A3-P, Sequence Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-B3-22 | H Type Pressure Control Valve HT-06-B3, Sequence Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-B3-P-22 | H Type Pressure Control Valve HT-06-B3-P, Sequence Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-C3-22 | H Type Pressure Control Valve HT-06-C3, Sequence Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-C3-P-22 | H Type Pressure Control Valve HT-06-C3-P, Sequence Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-L4-22 | H Type Pressure Control Valve HT-06-L4, Unloading Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-M4-22 | H Type Pressure Control Valve HT-06-M4, Unloading Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-N4-22 | H Type Pressure Control Valve HT-06-N4, Unloading Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-N4-P-22 | H Type Pressure Control Valve HT-06-N4-P, Unloading Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-A4-22 | H Type Pressure Control Valve HT-06-A4, Unloading Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-A4-P-22 | H Type Pressure Control Valve HT-06-A4-P, Unloading Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-B4-22 | H Type Pressure Control Valve HT-06-B4, Unloading Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-B4-P-22 | H Type Pressure Control Valve HT-06-B4-P, Unloading Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-C4-22 | H Type Pressure Control Valve HT-06-C4, Unloading Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 | |
| HT-06-C4-P-22 | H Type Pressure Control Valve HT-06-C4-P, Unloading Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.2 kg | Design No.: 22 |
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 250 L/min. H type, Threaded mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 12.0 kg.
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 250 L/min. H type, Threaded mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 12.0 kg.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| HT-10-L1-22 | H Type Pressure Control Valve HT-10-L1, Low Pressure Relief Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-M1-22 | H Type Pressure Control Valve HT-10-M1, Low Pressure Relief Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-L2-22 | H Type Pressure Control Valve HT-10-L2, Sequence Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-M2-22 | H Type Pressure Control Valve HT-10-M2, Sequence Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-N2-22 | H Type Pressure Control Valve HT-10-N2, Sequence Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-N2-P-22 | H Type Pressure Control Valve HT-10-N2-P, Sequence Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-A2-22 | H Type Pressure Control Valve HT-10-A2, Sequence Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-A2-P-22 | H Type Pressure Control Valve HT-10-A2-P, Sequence Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-B2-22 | H Type Pressure Control Valve HT-10-B2, Sequence Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-B2-P-22 | H Type Pressure Control Valve HT-10-B2-P, Sequence Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-C2-22 | H Type Pressure Control Valve HT-10-C2, Sequence Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-C2-P-22 | H Type Pressure Control Valve HT-10-C2-P, Sequence Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-L3-22 | H Type Pressure Control Valve HT-10-L3, Sequence Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-M3-22 | H Type Pressure Control Valve HT-10-M3, Sequence Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-N3-22 | H Type Pressure Control Valve HT-10-N3, Sequence Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-N3-P-22 | H Type Pressure Control Valve HT-10-N3-P, Sequence Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-A3-22 | H Type Pressure Control Valve HT-10-A3, Sequence Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-A3-P-22 | H Type Pressure Control Valve HT-10-A3-P, Sequence Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-B3-22 | H Type Pressure Control Valve HT-10-B3, Sequence Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-B3-P-22 | H Type Pressure Control Valve HT-10-B3-P, Sequence Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-C3-22 | H Type Pressure Control Valve HT-10-C3, Sequence Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-C3-P-22 | H Type Pressure Control Valve HT-10-C3-P, Sequence Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-L4-22 | H Type Pressure Control Valve HT-10-L4, Unloading Valve, range L | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-M4-22 | H Type Pressure Control Valve HT-10-M4, Unloading Valve, range M | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-N4-22 | H Type Pressure Control Valve HT-10-N4, Unloading Valve, range N | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-N4-P-22 | H Type Pressure Control Valve HT-10-N4-P, Unloading Valve, range N, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-A4-22 | H Type Pressure Control Valve HT-10-A4, Unloading Valve, range A | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-A4-P-22 | H Type Pressure Control Valve HT-10-A4-P, Unloading Valve, range A, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-B4-22 | H Type Pressure Control Valve HT-10-B4, Unloading Valve, range B | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-B4-P-22 | H Type Pressure Control Valve HT-10-B4-P, Unloading Valve, range B, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-C4-22 | H Type Pressure Control Valve HT-10-C4, Unloading Valve, range C | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 | |
| HT-10-C4-P-22 | H Type Pressure Control Valve HT-10-C4-P, Unloading Valve, range C, aux pilot | Yuken | Type: H Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 12.0 kg | Design No.: 22 |
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 50 L/min. HC type, Sub-plate mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 4.8 kg.
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 50 L/min. HC type, Sub-plate mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 4.8 kg.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| HCG-03-L1-22 | HC Type Pressure Control Valve HCG-03-L1, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-M1-22 | HC Type Pressure Control Valve HCG-03-M1, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-N1-22 | HC Type Pressure Control Valve HCG-03-N1, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-N1-P-22 | HC Type Pressure Control Valve HCG-03-N1-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-A1-22 | HC Type Pressure Control Valve HCG-03-A1, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-A1-P-22 | HC Type Pressure Control Valve HCG-03-A1-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-B1-22 | HC Type Pressure Control Valve HCG-03-B1, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-B1-P-22 | HC Type Pressure Control Valve HCG-03-B1-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-C1-22 | HC Type Pressure Control Valve HCG-03-C1, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-C1-P-22 | HC Type Pressure Control Valve HCG-03-C1-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-L2-22 | HC Type Pressure Control Valve HCG-03-L2, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-M2-22 | HC Type Pressure Control Valve HCG-03-M2, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-N2-22 | HC Type Pressure Control Valve HCG-03-N2, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-N2-P-22 | HC Type Pressure Control Valve HCG-03-N2-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-A2-22 | HC Type Pressure Control Valve HCG-03-A2, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-A2-P-22 | HC Type Pressure Control Valve HCG-03-A2-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-B2-22 | HC Type Pressure Control Valve HCG-03-B2, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-B2-P-22 | HC Type Pressure Control Valve HCG-03-B2-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-C2-22 | HC Type Pressure Control Valve HCG-03-C2, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-C2-P-22 | HC Type Pressure Control Valve HCG-03-C2-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-L3-22 | HC Type Pressure Control Valve HCG-03-L3, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-M3-22 | HC Type Pressure Control Valve HCG-03-M3, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-N3-22 | HC Type Pressure Control Valve HCG-03-N3, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-N3-P-22 | HC Type Pressure Control Valve HCG-03-N3-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-A3-22 | HC Type Pressure Control Valve HCG-03-A3, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-A3-P-22 | HC Type Pressure Control Valve HCG-03-A3-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-B3-22 | HC Type Pressure Control Valve HCG-03-B3, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-B3-P-22 | HC Type Pressure Control Valve HCG-03-B3-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-C3-22 | HC Type Pressure Control Valve HCG-03-C3, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-C3-P-22 | HC Type Pressure Control Valve HCG-03-C3-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-L4-22 | HC Type Pressure Control Valve HCG-03-L4, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-M4-22 | HC Type Pressure Control Valve HCG-03-M4, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-N4-22 | HC Type Pressure Control Valve HCG-03-N4, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-N4-P-22 | HC Type Pressure Control Valve HCG-03-N4-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-A4-22 | HC Type Pressure Control Valve HCG-03-A4, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-A4-P-22 | HC Type Pressure Control Valve HCG-03-A4-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-B4-22 | HC Type Pressure Control Valve HCG-03-B4, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-B4-P-22 | HC Type Pressure Control Valve HCG-03-B4-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-C4-22 | HC Type Pressure Control Valve HCG-03-C4, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 | |
| HCG-03-C4-P-22 | HC Type Pressure Control Valve HCG-03-C4-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.8 kg | Design No.: 22 |
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 125 L/min. HC type, Sub-plate mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 7.4 kg.
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 125 L/min. HC type, Sub-plate mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 7.4 kg.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| HCG-06-L1-22 | HC Type Pressure Control Valve HCG-06-L1, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-M1-22 | HC Type Pressure Control Valve HCG-06-M1, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-N1-22 | HC Type Pressure Control Valve HCG-06-N1, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-N1-P-22 | HC Type Pressure Control Valve HCG-06-N1-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-A1-22 | HC Type Pressure Control Valve HCG-06-A1, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-A1-P-22 | HC Type Pressure Control Valve HCG-06-A1-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-B1-22 | HC Type Pressure Control Valve HCG-06-B1, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-B1-P-22 | HC Type Pressure Control Valve HCG-06-B1-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-C1-22 | HC Type Pressure Control Valve HCG-06-C1, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-C1-P-22 | HC Type Pressure Control Valve HCG-06-C1-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-L2-22 | HC Type Pressure Control Valve HCG-06-L2, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-M2-22 | HC Type Pressure Control Valve HCG-06-M2, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-N2-22 | HC Type Pressure Control Valve HCG-06-N2, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-N2-P-22 | HC Type Pressure Control Valve HCG-06-N2-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-A2-22 | HC Type Pressure Control Valve HCG-06-A2, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-A2-P-22 | HC Type Pressure Control Valve HCG-06-A2-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-B2-22 | HC Type Pressure Control Valve HCG-06-B2, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-B2-P-22 | HC Type Pressure Control Valve HCG-06-B2-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-C2-22 | HC Type Pressure Control Valve HCG-06-C2, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-C2-P-22 | HC Type Pressure Control Valve HCG-06-C2-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-L3-22 | HC Type Pressure Control Valve HCG-06-L3, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-M3-22 | HC Type Pressure Control Valve HCG-06-M3, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-N3-22 | HC Type Pressure Control Valve HCG-06-N3, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-N3-P-22 | HC Type Pressure Control Valve HCG-06-N3-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-A3-22 | HC Type Pressure Control Valve HCG-06-A3, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-A3-P-22 | HC Type Pressure Control Valve HCG-06-A3-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-B3-22 | HC Type Pressure Control Valve HCG-06-B3, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-B3-P-22 | HC Type Pressure Control Valve HCG-06-B3-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-C3-22 | HC Type Pressure Control Valve HCG-06-C3, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-C3-P-22 | HC Type Pressure Control Valve HCG-06-C3-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-L4-22 | HC Type Pressure Control Valve HCG-06-L4, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-M4-22 | HC Type Pressure Control Valve HCG-06-M4, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-N4-22 | HC Type Pressure Control Valve HCG-06-N4, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-N4-P-22 | HC Type Pressure Control Valve HCG-06-N4-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-A4-22 | HC Type Pressure Control Valve HCG-06-A4, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-A4-P-22 | HC Type Pressure Control Valve HCG-06-A4-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-B4-22 | HC Type Pressure Control Valve HCG-06-B4, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-B4-P-22 | HC Type Pressure Control Valve HCG-06-B4-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-C4-22 | HC Type Pressure Control Valve HCG-06-C4, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 | |
| HCG-06-C4-P-22 | HC Type Pressure Control Valve HCG-06-C4-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.4 kg | Design No.: 22 |
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 250 L/min. HC type, Sub-plate mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 13.8 kg.
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 250 L/min. HC type, Sub-plate mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 13.8 kg.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| HCG-10-L1-22 | HC Type Pressure Control Valve HCG-10-L1, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-M1-22 | HC Type Pressure Control Valve HCG-10-M1, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-N1-22 | HC Type Pressure Control Valve HCG-10-N1, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-N1-P-22 | HC Type Pressure Control Valve HCG-10-N1-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-A1-22 | HC Type Pressure Control Valve HCG-10-A1, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-A1-P-22 | HC Type Pressure Control Valve HCG-10-A1-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-B1-22 | HC Type Pressure Control Valve HCG-10-B1, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-B1-P-22 | HC Type Pressure Control Valve HCG-10-B1-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-C1-22 | HC Type Pressure Control Valve HCG-10-C1, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-C1-P-22 | HC Type Pressure Control Valve HCG-10-C1-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-L2-22 | HC Type Pressure Control Valve HCG-10-L2, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-M2-22 | HC Type Pressure Control Valve HCG-10-M2, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-N2-22 | HC Type Pressure Control Valve HCG-10-N2, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-N2-P-22 | HC Type Pressure Control Valve HCG-10-N2-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-A2-22 | HC Type Pressure Control Valve HCG-10-A2, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-A2-P-22 | HC Type Pressure Control Valve HCG-10-A2-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-B2-22 | HC Type Pressure Control Valve HCG-10-B2, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-B2-P-22 | HC Type Pressure Control Valve HCG-10-B2-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-C2-22 | HC Type Pressure Control Valve HCG-10-C2, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-C2-P-22 | HC Type Pressure Control Valve HCG-10-C2-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-L3-22 | HC Type Pressure Control Valve HCG-10-L3, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-M3-22 | HC Type Pressure Control Valve HCG-10-M3, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-N3-22 | HC Type Pressure Control Valve HCG-10-N3, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-N3-P-22 | HC Type Pressure Control Valve HCG-10-N3-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-A3-22 | HC Type Pressure Control Valve HCG-10-A3, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-A3-P-22 | HC Type Pressure Control Valve HCG-10-A3-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-B3-22 | HC Type Pressure Control Valve HCG-10-B3, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-B3-P-22 | HC Type Pressure Control Valve HCG-10-B3-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-C3-22 | HC Type Pressure Control Valve HCG-10-C3, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-C3-P-22 | HC Type Pressure Control Valve HCG-10-C3-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-L4-22 | HC Type Pressure Control Valve HCG-10-L4, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-M4-22 | HC Type Pressure Control Valve HCG-10-M4, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-N4-22 | HC Type Pressure Control Valve HCG-10-N4, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-N4-P-22 | HC Type Pressure Control Valve HCG-10-N4-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-A4-22 | HC Type Pressure Control Valve HCG-10-A4, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-A4-P-22 | HC Type Pressure Control Valve HCG-10-A4-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-B4-22 | HC Type Pressure Control Valve HCG-10-B4, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-B4-P-22 | HC Type Pressure Control Valve HCG-10-B4-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-C4-22 | HC Type Pressure Control Valve HCG-10-C4, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCG-10-C4-P-22 | HC Type Pressure Control Valve HCG-10-C4-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 |
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 50 L/min. HC type, Threaded mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 4.1 kg.
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 50 L/min. HC type, Threaded mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 4.1 kg.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| HCT-03-L1-22 | HC Type Pressure Control Valve HCT-03-L1, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-M1-22 | HC Type Pressure Control Valve HCT-03-M1, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-N1-22 | HC Type Pressure Control Valve HCT-03-N1, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-N1-P-22 | HC Type Pressure Control Valve HCT-03-N1-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-A1-22 | HC Type Pressure Control Valve HCT-03-A1, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-A1-P-22 | HC Type Pressure Control Valve HCT-03-A1-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-B1-22 | HC Type Pressure Control Valve HCT-03-B1, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-B1-P-22 | HC Type Pressure Control Valve HCT-03-B1-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-C1-22 | HC Type Pressure Control Valve HCT-03-C1, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-C1-P-22 | HC Type Pressure Control Valve HCT-03-C1-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-L2-22 | HC Type Pressure Control Valve HCT-03-L2, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-M2-22 | HC Type Pressure Control Valve HCT-03-M2, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-N2-22 | HC Type Pressure Control Valve HCT-03-N2, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-N2-P-22 | HC Type Pressure Control Valve HCT-03-N2-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-A2-22 | HC Type Pressure Control Valve HCT-03-A2, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-A2-P-22 | HC Type Pressure Control Valve HCT-03-A2-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-B2-22 | HC Type Pressure Control Valve HCT-03-B2, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-B2-P-22 | HC Type Pressure Control Valve HCT-03-B2-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-C2-22 | HC Type Pressure Control Valve HCT-03-C2, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-C2-P-22 | HC Type Pressure Control Valve HCT-03-C2-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-L3-22 | HC Type Pressure Control Valve HCT-03-L3, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-M3-22 | HC Type Pressure Control Valve HCT-03-M3, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-N3-22 | HC Type Pressure Control Valve HCT-03-N3, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-N3-P-22 | HC Type Pressure Control Valve HCT-03-N3-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-A3-22 | HC Type Pressure Control Valve HCT-03-A3, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-A3-P-22 | HC Type Pressure Control Valve HCT-03-A3-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-B3-22 | HC Type Pressure Control Valve HCT-03-B3, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-B3-P-22 | HC Type Pressure Control Valve HCT-03-B3-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-C3-22 | HC Type Pressure Control Valve HCT-03-C3, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-C3-P-22 | HC Type Pressure Control Valve HCT-03-C3-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-L4-22 | HC Type Pressure Control Valve HCT-03-L4, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-M4-22 | HC Type Pressure Control Valve HCT-03-M4, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-N4-22 | HC Type Pressure Control Valve HCT-03-N4, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-N4-P-22 | HC Type Pressure Control Valve HCT-03-N4-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-A4-22 | HC Type Pressure Control Valve HCT-03-A4, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-A4-P-22 | HC Type Pressure Control Valve HCT-03-A4-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-B4-22 | HC Type Pressure Control Valve HCT-03-B4, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-B4-P-22 | HC Type Pressure Control Valve HCT-03-B4-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-C4-22 | HC Type Pressure Control Valve HCT-03-C4, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 | |
| HCT-03-C4-P-22 | HC Type Pressure Control Valve HCT-03-C4-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 03 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 50 L/min | Mass: 4.1 kg | Design No.: 22 |
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 125 L/min. HC type, Threaded mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 7.1 kg.
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 125 L/min. HC type, Threaded mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 7.1 kg.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| HCT-06-L1-22 | HC Type Pressure Control Valve HCT-06-L1, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-M1-22 | HC Type Pressure Control Valve HCT-06-M1, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-N1-22 | HC Type Pressure Control Valve HCT-06-N1, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-N1-P-22 | HC Type Pressure Control Valve HCT-06-N1-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-A1-22 | HC Type Pressure Control Valve HCT-06-A1, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-A1-P-22 | HC Type Pressure Control Valve HCT-06-A1-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-B1-22 | HC Type Pressure Control Valve HCT-06-B1, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-B1-P-22 | HC Type Pressure Control Valve HCT-06-B1-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-C1-22 | HC Type Pressure Control Valve HCT-06-C1, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-C1-P-22 | HC Type Pressure Control Valve HCT-06-C1-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-L2-22 | HC Type Pressure Control Valve HCT-06-L2, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-M2-22 | HC Type Pressure Control Valve HCT-06-M2, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-N2-22 | HC Type Pressure Control Valve HCT-06-N2, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-N2-P-22 | HC Type Pressure Control Valve HCT-06-N2-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-A2-22 | HC Type Pressure Control Valve HCT-06-A2, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-A2-P-22 | HC Type Pressure Control Valve HCT-06-A2-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-B2-22 | HC Type Pressure Control Valve HCT-06-B2, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-B2-P-22 | HC Type Pressure Control Valve HCT-06-B2-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-C2-22 | HC Type Pressure Control Valve HCT-06-C2, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-C2-P-22 | HC Type Pressure Control Valve HCT-06-C2-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-L3-22 | HC Type Pressure Control Valve HCT-06-L3, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-M3-22 | HC Type Pressure Control Valve HCT-06-M3, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-N3-22 | HC Type Pressure Control Valve HCT-06-N3, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-N3-P-22 | HC Type Pressure Control Valve HCT-06-N3-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-A3-22 | HC Type Pressure Control Valve HCT-06-A3, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-A3-P-22 | HC Type Pressure Control Valve HCT-06-A3-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-B3-22 | HC Type Pressure Control Valve HCT-06-B3, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-B3-P-22 | HC Type Pressure Control Valve HCT-06-B3-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-C3-22 | HC Type Pressure Control Valve HCT-06-C3, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-C3-P-22 | HC Type Pressure Control Valve HCT-06-C3-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-L4-22 | HC Type Pressure Control Valve HCT-06-L4, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-M4-22 | HC Type Pressure Control Valve HCT-06-M4, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-N4-22 | HC Type Pressure Control Valve HCT-06-N4, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-N4-P-22 | HC Type Pressure Control Valve HCT-06-N4-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-A4-22 | HC Type Pressure Control Valve HCT-06-A4, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-A4-P-22 | HC Type Pressure Control Valve HCT-06-A4-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-B4-22 | HC Type Pressure Control Valve HCT-06-B4, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-B4-P-22 | HC Type Pressure Control Valve HCT-06-B4-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-C4-22 | HC Type Pressure Control Valve HCT-06-C4, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | |
| HCT-06-C4-P-22 | HC Type Pressure Control Valve HCT-06-C4-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 |
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 250 L/min. HC type, Threaded mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 13.8 kg.
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 250 L/min. HC type, Threaded mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 13.8 kg.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| HCT-10-L1-22 | HC Type Pressure Control Valve HCT-10-L1, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-M1-22 | HC Type Pressure Control Valve HCT-10-M1, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-N1-22 | HC Type Pressure Control Valve HCT-10-N1, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-N1-P-22 | HC Type Pressure Control Valve HCT-10-N1-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-A1-22 | HC Type Pressure Control Valve HCT-10-A1, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-A1-P-22 | HC Type Pressure Control Valve HCT-10-A1-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-B1-22 | HC Type Pressure Control Valve HCT-10-B1, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-B1-P-22 | HC Type Pressure Control Valve HCT-10-B1-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-C1-22 | HC Type Pressure Control Valve HCT-10-C1, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-C1-P-22 | HC Type Pressure Control Valve HCT-10-C1-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-L2-22 | HC Type Pressure Control Valve HCT-10-L2, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-M2-22 | HC Type Pressure Control Valve HCT-10-M2, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-N2-22 | HC Type Pressure Control Valve HCT-10-N2, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-N2-P-22 | HC Type Pressure Control Valve HCT-10-N2-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-A2-22 | HC Type Pressure Control Valve HCT-10-A2, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-A2-P-22 | HC Type Pressure Control Valve HCT-10-A2-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-B2-22 | HC Type Pressure Control Valve HCT-10-B2, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-B2-P-22 | HC Type Pressure Control Valve HCT-10-B2-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-C2-22 | HC Type Pressure Control Valve HCT-10-C2, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-C2-P-22 | HC Type Pressure Control Valve HCT-10-C2-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-L3-22 | HC Type Pressure Control Valve HCT-10-L3, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-M3-22 | HC Type Pressure Control Valve HCT-10-M3, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-N3-22 | HC Type Pressure Control Valve HCT-10-N3, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-N3-P-22 | HC Type Pressure Control Valve HCT-10-N3-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-A3-22 | HC Type Pressure Control Valve HCT-10-A3, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-A3-P-22 | HC Type Pressure Control Valve HCT-10-A3-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-B3-22 | HC Type Pressure Control Valve HCT-10-B3, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-B3-P-22 | HC Type Pressure Control Valve HCT-10-B3-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-C3-22 | HC Type Pressure Control Valve HCT-10-C3, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-C3-P-22 | HC Type Pressure Control Valve HCT-10-C3-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-L4-22 | HC Type Pressure Control Valve HCT-10-L4, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-M4-22 | HC Type Pressure Control Valve HCT-10-M4, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-N4-22 | HC Type Pressure Control Valve HCT-10-N4, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-N4-P-22 | HC Type Pressure Control Valve HCT-10-N4-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-A4-22 | HC Type Pressure Control Valve HCT-10-A4, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-A4-P-22 | HC Type Pressure Control Valve HCT-10-A4-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-B4-22 | HC Type Pressure Control Valve HCT-10-B4, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-B4-P-22 | HC Type Pressure Control Valve HCT-10-B4-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-C4-22 | HC Type Pressure Control Valve HCT-10-C4, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 | |
| HCT-10-C4-P-22 | HC Type Pressure Control Valve HCT-10-C4-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 10 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 250 L/min | Mass: 13.8 kg | Design No.: 22 |
![[Yuken] — Low Noise Pilot Operated Relief Valve (S-BG-03/06/10)](https://img.prosourcemro.com/2026/05/002-27-257x300.png)
Low Noise Type Pilot Operated Relief Valves. Max. operating pressure: 25 MPa. Pressure adjustment range: to 25 MPa. Max. flow: 100/200/400 L/min (03/06/10). Sub-plate mounting. Pressure adjustment handle direction: L (left, standard) / R (right). High-vent type (-V) available.
Low Noise Type Pilot Operated Relief Valves. Max. operating pressure: 25 MPa. Pressure adjustment range: to 25 MPa. Max. flow: 100/200/400 L/min (03/06/10). Sub-plate mounting. Pressure adjustment handle direction: L (left, standard) / R (right). High-vent type (-V) available.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| S-BG-03-L-40 | Low Noise Relief Valve S-BG-03-L, sub-plate, handle L | Yuken | Type: Low Noise Pilot Operated Relief Valve | Mounting: Sub-plate | Valve Size: 03 | High-Vent Type: No | Handle Direction: L (Left (standard)) | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: to 25 MPa | Max. Flow: 100 L/min | Mass: 4.1 kg | Design No.: 40 | |
| S-BG-03-R-40 | Low Noise Relief Valve S-BG-03-R, sub-plate, handle R | Yuken | Type: Low Noise Pilot Operated Relief Valve | Mounting: Sub-plate | Valve Size: 03 | High-Vent Type: No | Handle Direction: R (Right) | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: to 25 MPa | Max. Flow: 100 L/min | Mass: 4.1 kg | Design No.: 40 | |
| S-BG-03-V-L-40 | Low Noise Relief Valve S-BG-03-V-L, sub-plate, handle L, high-vent | Yuken | Type: Low Noise Pilot Operated Relief Valve | Mounting: Sub-plate | Valve Size: 03 | High-Vent Type: Yes (-V) | Handle Direction: L (Left (standard)) | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: to 25 MPa | Max. Flow: 100 L/min | Mass: 4.1 kg | Design No.: 40 | |
| S-BG-03-V-R-40 | Low Noise Relief Valve S-BG-03-V-R, sub-plate, handle R, high-vent | Yuken | Type: Low Noise Pilot Operated Relief Valve | Mounting: Sub-plate | Valve Size: 03 | High-Vent Type: Yes (-V) | Handle Direction: R (Right) | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: to 25 MPa | Max. Flow: 100 L/min | Mass: 4.1 kg | Design No.: 40 | |
| S-BG-06-L-40 | Low Noise Relief Valve S-BG-06-L, sub-plate, handle L | Yuken | Type: Low Noise Pilot Operated Relief Valve | Mounting: Sub-plate | Valve Size: 06 | High-Vent Type: No | Handle Direction: L (Left (standard)) | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: to 25 MPa | Max. Flow: 200 L/min | Mass: 5.0 kg | Design No.: 40 | |
| S-BG-06-R-40 | Low Noise Relief Valve S-BG-06-R, sub-plate, handle R | Yuken | Type: Low Noise Pilot Operated Relief Valve | Mounting: Sub-plate | Valve Size: 06 | High-Vent Type: No | Handle Direction: R (Right) | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: to 25 MPa | Max. Flow: 200 L/min | Mass: 5.0 kg | Design No.: 40 | |
| S-BG-06-V-L-40 | Low Noise Relief Valve S-BG-06-V-L, sub-plate, handle L, high-vent | Yuken | Type: Low Noise Pilot Operated Relief Valve | Mounting: Sub-plate | Valve Size: 06 | High-Vent Type: Yes (-V) | Handle Direction: L (Left (standard)) | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: to 25 MPa | Max. Flow: 200 L/min | Mass: 5.0 kg | Design No.: 40 | |
| S-BG-06-V-R-40 | Low Noise Relief Valve S-BG-06-V-R, sub-plate, handle R, high-vent | Yuken | Type: Low Noise Pilot Operated Relief Valve | Mounting: Sub-plate | Valve Size: 06 | High-Vent Type: Yes (-V) | Handle Direction: R (Right) | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: to 25 MPa | Max. Flow: 200 L/min | Mass: 5.0 kg | Design No.: 40 | |
| S-BG-10-L-40 | Low Noise Relief Valve S-BG-10-L, sub-plate, handle L | Yuken | Type: Low Noise Pilot Operated Relief Valve | Mounting: Sub-plate | Valve Size: 10 | High-Vent Type: No | Handle Direction: L (Left (standard)) | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: to 25 MPa | Max. Flow: 400 L/min | Mass: 10.5 kg | Design No.: 40 | |
| S-BG-10-R-40 | Low Noise Relief Valve S-BG-10-R, sub-plate, handle R | Yuken | Type: Low Noise Pilot Operated Relief Valve | Mounting: Sub-plate | Valve Size: 10 | High-Vent Type: No | Handle Direction: R (Right) | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: to 25 MPa | Max. Flow: 400 L/min | Mass: 10.5 kg | Design No.: 40 | |
| S-BG-10-V-L-40 | Low Noise Relief Valve S-BG-10-V-L, sub-plate, handle L, high-vent | Yuken | Type: Low Noise Pilot Operated Relief Valve | Mounting: Sub-plate | Valve Size: 10 | High-Vent Type: Yes (-V) | Handle Direction: L (Left (standard)) | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: to 25 MPa | Max. Flow: 400 L/min | Mass: 10.5 kg | Design No.: 40 | |
| S-BG-10-V-R-40 | Low Noise Relief Valve S-BG-10-V-R, sub-plate, handle R, high-vent | Yuken | Type: Low Noise Pilot Operated Relief Valve | Mounting: Sub-plate | Valve Size: 10 | High-Vent Type: Yes (-V) | Handle Direction: R (Right) | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: to 25 MPa | Max. Flow: 400 L/min | Mass: 10.5 kg | Design No.: 40 |
![[YUKEN] — LSVG-01EH On-Board Electronic Direct Linear Servo Valve](https://img.prosourcemro.com/2026/05/002-152-300x224.png)
On-board electronic (OBE) type direct-operated linear servo valve, realizing the 'high precision, simple, convenient' concept of the LSVG and LSVHG-EH series in a direct-operated form. Hysteresis 0.1% or less; step response 3 ms; frequency response up to 260 Hz. Operates from a DC 24 V supply with command-signal input only; built-in amplifier with fault-diagnosis indicator. Usable to NAS 1638 class 10 (ISO4406 21/19/15). Safety device PABT / PBAT / neutral; connector 6+PE / 11+PE; dry (Y-port) or wet (no Y-port) type — selectable per order.
On-board electronic (OBE) type direct-operated linear servo valve, realizing the 'high precision, simple, convenient' concept of the LSVG and LSVHG-EH series in a direct-operated form. Hysteresis 0.1% or less; step response 3 ms; frequency response up to 260 Hz. Operates from a DC 24 V supply with command-signal input only; built-in amplifier with fault-diagnosis indicator. Usable to NAS 1638 class 10 (ISO4406 21/19/15). Safety device PABT / PBAT / neutral; connector 6+PE / 11+PE; dry (Y-port) or wet (no Y-port) type — selectable per order.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| LSVG-01EH-4-A | LSVG-01EH OBE Direct Servo Valve, 4 L/min, input A | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 4 L/min | Input Signal / Spool Monitor: A: Voltage ±10 V (+input → PBAT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 0.4 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-4-B | LSVG-01EH OBE Direct Servo Valve, 4 L/min, input B | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 4 L/min | Input Signal / Spool Monitor: B: Current 4–20 mA (12–20 mA input → PBAT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 0.4 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-4-C | LSVG-01EH OBE Direct Servo Valve, 4 L/min, input C | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 4 L/min | Input Signal / Spool Monitor: C: Current ±10 mA (+input → PBAT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 0.4 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-4-D | LSVG-01EH OBE Direct Servo Valve, 4 L/min, input D | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 4 L/min | Input Signal / Spool Monitor: D: Voltage ±10 V (+input → PABT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 0.4 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-4-E | LSVG-01EH OBE Direct Servo Valve, 4 L/min, input E | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 4 L/min | Input Signal / Spool Monitor: E: Current 4–20 mA (12–20 mA input → PABT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 0.4 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-4-F | LSVG-01EH OBE Direct Servo Valve, 4 L/min, input F | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 4 L/min | Input Signal / Spool Monitor: F: Current ±10 mA (+input → PABT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 0.4 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-10-A | LSVG-01EH OBE Direct Servo Valve, 10 L/min, input A | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 10 L/min | Input Signal / Spool Monitor: A: Voltage ±10 V (+input → PBAT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 0.8 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-10-B | LSVG-01EH OBE Direct Servo Valve, 10 L/min, input B | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 10 L/min | Input Signal / Spool Monitor: B: Current 4–20 mA (12–20 mA input → PBAT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 0.8 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-10-C | LSVG-01EH OBE Direct Servo Valve, 10 L/min, input C | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 10 L/min | Input Signal / Spool Monitor: C: Current ±10 mA (+input → PBAT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 0.8 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-10-D | LSVG-01EH OBE Direct Servo Valve, 10 L/min, input D | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 10 L/min | Input Signal / Spool Monitor: D: Voltage ±10 V (+input → PABT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 0.8 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-10-E | LSVG-01EH OBE Direct Servo Valve, 10 L/min, input E | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 10 L/min | Input Signal / Spool Monitor: E: Current 4–20 mA (12–20 mA input → PABT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 0.8 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-10-F | LSVG-01EH OBE Direct Servo Valve, 10 L/min, input F | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 10 L/min | Input Signal / Spool Monitor: F: Current ±10 mA (+input → PABT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 0.8 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-20-A | LSVG-01EH OBE Direct Servo Valve, 20 L/min, input A | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 20 L/min | Input Signal / Spool Monitor: A: Voltage ±10 V (+input → PBAT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.2 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-20-B | LSVG-01EH OBE Direct Servo Valve, 20 L/min, input B | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 20 L/min | Input Signal / Spool Monitor: B: Current 4–20 mA (12–20 mA input → PBAT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.2 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-20-C | LSVG-01EH OBE Direct Servo Valve, 20 L/min, input C | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 20 L/min | Input Signal / Spool Monitor: C: Current ±10 mA (+input → PBAT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.2 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-20-D | LSVG-01EH OBE Direct Servo Valve, 20 L/min, input D | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 20 L/min | Input Signal / Spool Monitor: D: Voltage ±10 V (+input → PABT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.2 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-20-E | LSVG-01EH OBE Direct Servo Valve, 20 L/min, input E | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 20 L/min | Input Signal / Spool Monitor: E: Current 4–20 mA (12–20 mA input → PABT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.2 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-01EH-20-F | LSVG-01EH OBE Direct Servo Valve, 20 L/min, input F | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 01 (ISO 4401-03) | Rated Flow (ΔP=7MPa): 20 L/min | Input Signal / Spool Monitor: F: Current ±10 mA (+input → PABT flow) | Max Operating Pressure: 35 MPa | Tank Port Pressure: 21 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.2 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 240 Hz (230) | Frequency Resp. (−90° phase): 300 Hz (270) | Spool Rated Stroke: ±0.5 mm | Mass: 4.3 kg | Mounting Bolts: M5×55L ×4 (6.0–8.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 |
![[YUKEN] — LSVG-03 Direct Type High-Speed Linear Servo Valve](https://img.prosourcemro.com/2026/05/002-149-300x182.png)
Direct type high-speed linear servo valve using a compact, powerful linear motor as the actuator, with the moving coil, spool, and position sensor combined in series for a very simple structure. Hysteresis 0.1% or less; step response 2 ms (size 60: 3 ms); frequency response −3 dB gain up to 350 Hz. Excellent vibration resistance from the simple construction and superior contamination tolerance, usable to NAS 1638 class 10 (ISO4406 21/19/15). Max operating pressure 35 MPa. Neutral zero-lap spool. Requires dedicated AMLS linear servo amplifier.
Direct type high-speed linear servo valve using a compact, powerful linear motor as the actuator, with the moving coil, spool, and position sensor combined in series for a very simple structure. Hysteresis 0.1% or less; step response 2 ms (size 60: 3 ms); frequency response −3 dB gain up to 350 Hz. Excellent vibration resistance from the simple construction and superior contamination tolerance, usable to NAS 1638 class 10 (ISO4406 21/19/15). Max operating pressure 35 MPa. Neutral zero-lap spool. Requires dedicated AMLS linear servo amplifier.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| LSVG-03-4-10 | LSVG-03 Direct Linear Servo Valve, 4 L/min (ΔP=7MPa) | YUKEN | Type: Direct (single-stage), neutral zero-lap | Valve Size: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 4 L/min | Max Operating Pressure: 35 MPa | Tank Port Pressure: 35 MPa | Drain Port Y Back Pressure: 0.05 MPa max | Hysteresis: 0.1% max | Step Response (0↔100%): 2 ms (3) | Frequency Resp. (−3 dB gain): 350 Hz (300) | Frequency Resp. (−90° phase): 450 Hz (370) | Spool Rated Stroke: ±0.5 mm | Linear Motor: 2 A (6 A max), coil 4.5 Ω @20°C | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Protection: IP64 | Ambient Temp: −15 to +60 °C | Mass: 5 kg | Mounting Bolts: M8×65L ×4, 30.8–37.7 N·m (M6 spec on request) | Dedicated Amplifier: AMLS-A-D48/D24 | Cable Port Direction: Top (standard) / R (right) / L (left) — select per order | Fluid: Mineral oil (standard) / Phosphate-ester (F prefix, fluoro rubber seals) | Source: Yuken Cat. I-Edit0, I-5/I-6 | |
| LSVG-03-10-10 | LSVG-03 Direct Linear Servo Valve, 10 L/min (ΔP=7MPa) | YUKEN | Type: Direct (single-stage), neutral zero-lap | Valve Size: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 10 L/min | Max Operating Pressure: 35 MPa | Tank Port Pressure: 35 MPa | Drain Port Y Back Pressure: 0.05 MPa max | Hysteresis: 0.1% max | Step Response (0↔100%): 2 ms (3) | Frequency Resp. (−3 dB gain): 350 Hz (300) | Frequency Resp. (−90° phase): 450 Hz (370) | Spool Rated Stroke: ±0.5 mm | Linear Motor: 2 A (6 A max), coil 4.5 Ω @20°C | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Protection: IP64 | Ambient Temp: −15 to +60 °C | Mass: 5 kg | Mounting Bolts: M8×65L ×4, 30.8–37.7 N·m (M6 spec on request) | Dedicated Amplifier: AMLS-A-D48/D24 | Cable Port Direction: Top (standard) / R (right) / L (left) — select per order | Fluid: Mineral oil (standard) / Phosphate-ester (F prefix, fluoro rubber seals) | Source: Yuken Cat. I-Edit0, I-5/I-6 | |
| LSVG-03-20-10 | LSVG-03 Direct Linear Servo Valve, 20 L/min (ΔP=7MPa) | YUKEN | Type: Direct (single-stage), neutral zero-lap | Valve Size: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 20 L/min | Max Operating Pressure: 35 MPa | Tank Port Pressure: 35 MPa | Drain Port Y Back Pressure: 0.05 MPa max | Hysteresis: 0.1% max | Step Response (0↔100%): 2 ms (3) | Frequency Resp. (−3 dB gain): 350 Hz (300) | Frequency Resp. (−90° phase): 450 Hz (370) | Spool Rated Stroke: ±0.5 mm | Linear Motor: 2 A (6 A max), coil 4.5 Ω @20°C | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Protection: IP64 | Ambient Temp: −15 to +60 °C | Mass: 5 kg | Mounting Bolts: M8×65L ×4, 30.8–37.7 N·m (M6 spec on request) | Dedicated Amplifier: AMLS-A-D48/D24 | Cable Port Direction: Top (standard) / R (right) / L (left) — select per order | Fluid: Mineral oil (standard) / Phosphate-ester (F prefix, fluoro rubber seals) | Source: Yuken Cat. I-Edit0, I-5/I-6 | |
| LSVG-03-40-10 | LSVG-03 Direct Linear Servo Valve, 40 L/min (ΔP=7MPa) | YUKEN | Type: Direct (single-stage), neutral zero-lap | Valve Size: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 40 L/min | Max Operating Pressure: 35 MPa | Tank Port Pressure: 35 MPa | Drain Port Y Back Pressure: 0.05 MPa max | Hysteresis: 0.1% max | Step Response (0↔100%): 2 ms (3) | Frequency Resp. (−3 dB gain): 350 Hz (300) | Frequency Resp. (−90° phase): 450 Hz (370) | Spool Rated Stroke: ±0.5 mm | Linear Motor: 2 A (6 A max), coil 4.5 Ω @20°C | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Protection: IP64 | Ambient Temp: −15 to +60 °C | Mass: 5 kg | Mounting Bolts: M8×65L ×4, 30.8–37.7 N·m (M6 spec on request) | Dedicated Amplifier: AMLS-A-D48/D24 | Cable Port Direction: Top (standard) / R (right) / L (left) — select per order | Fluid: Mineral oil (standard) / Phosphate-ester (F prefix, fluoro rubber seals) | Source: Yuken Cat. I-Edit0, I-5/I-6 | |
| LSVG-03-60-10 | LSVG-03 Direct Linear Servo Valve, 60 L/min (ΔP=7MPa) | YUKEN | Type: Direct (single-stage), neutral zero-lap | Valve Size: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 60 L/min | Max Operating Pressure: 35 MPa | Tank Port Pressure: 35 MPa | Drain Port Y Back Pressure: 0.05 MPa max | Hysteresis: 0.1% max | Step Response (0↔100%): 3 ms (4) | Frequency Resp. (−3 dB gain): 330 Hz (240) | Frequency Resp. (−90° phase): 410 Hz (330) | Spool Rated Stroke: ±0.75 mm | Linear Motor: 2 A (6 A max), coil 4.5 Ω @20°C | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Protection: IP64 | Ambient Temp: −15 to +60 °C | Mass: 5 kg | Mounting Bolts: M8×65L ×4, 30.8–37.7 N·m (M6 spec on request) | Dedicated Amplifier: AMLS-B-D48/D24 | Cable Port Direction: Top (standard) / R (right) / L (left) — select per order | Fluid: Mineral oil (standard) / Phosphate-ester (F prefix, fluoro rubber seals) | Source: Yuken Cat. I-Edit0, I-5/I-6 |
On-board electronic (OBE) type direct-operated linear servo valve, realizing the 'high precision, simple, convenient' concept of the LSVG and LSVHG-EH series in a direct-operated form. Hysteresis 0.1% or less; step response 3 ms; frequency response up to 260 Hz. Operates from a DC 24 V supply with command-signal input only; built-in amplifier with fault-diagnosis indicator. Usable to NAS 1638 class 10 (ISO4406 21/19/15). Safety device PABT / PBAT / neutral; connector 6+PE / 11+PE; dry (Y-port) or wet (no Y-port) type — selectable per order.
On-board electronic (OBE) type direct-operated linear servo valve, realizing the 'high precision, simple, convenient' concept of the LSVG and LSVHG-EH series in a direct-operated form. Hysteresis 0.1% or less; step response 3 ms; frequency response up to 260 Hz. Operates from a DC 24 V supply with command-signal input only; built-in amplifier with fault-diagnosis indicator. Usable to NAS 1638 class 10 (ISO4406 21/19/15). Safety device PABT / PBAT / neutral; connector 6+PE / 11+PE; dry (Y-port) or wet (no Y-port) type — selectable per order.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| LSVG-03EH-40-A | LSVG-03EH OBE Direct Servo Valve, 40 L/min, input A | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 40 L/min | Input Signal / Spool Monitor: A: Voltage ±10 V (+input → PBAT flow) | Max Operating Pressure: 35 (31.5 for 1006/M6-bolt type) MPa | Tank Port Pressure: 35 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 260 Hz (240) | Frequency Resp. (−90° phase): 310 Hz (310) | Spool Rated Stroke: ±0.75 mm | Mass: 5.2 kg | Mounting Bolts: M8×65L ×4 (30.8–37.7 N·m); 1006 type M6×60L ×4 (13.0–16.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-03EH-40-B | LSVG-03EH OBE Direct Servo Valve, 40 L/min, input B | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 40 L/min | Input Signal / Spool Monitor: B: Current 4–20 mA (12–20 mA input → PBAT flow) | Max Operating Pressure: 35 (31.5 for 1006/M6-bolt type) MPa | Tank Port Pressure: 35 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 260 Hz (240) | Frequency Resp. (−90° phase): 310 Hz (310) | Spool Rated Stroke: ±0.75 mm | Mass: 5.2 kg | Mounting Bolts: M8×65L ×4 (30.8–37.7 N·m); 1006 type M6×60L ×4 (13.0–16.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-03EH-40-C | LSVG-03EH OBE Direct Servo Valve, 40 L/min, input C | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 40 L/min | Input Signal / Spool Monitor: C: Current ±10 mA (+input → PBAT flow) | Max Operating Pressure: 35 (31.5 for 1006/M6-bolt type) MPa | Tank Port Pressure: 35 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 260 Hz (240) | Frequency Resp. (−90° phase): 310 Hz (310) | Spool Rated Stroke: ±0.75 mm | Mass: 5.2 kg | Mounting Bolts: M8×65L ×4 (30.8–37.7 N·m); 1006 type M6×60L ×4 (13.0–16.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-03EH-40-D | LSVG-03EH OBE Direct Servo Valve, 40 L/min, input D | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 40 L/min | Input Signal / Spool Monitor: D: Voltage ±10 V (+input → PABT flow) | Max Operating Pressure: 35 (31.5 for 1006/M6-bolt type) MPa | Tank Port Pressure: 35 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 260 Hz (240) | Frequency Resp. (−90° phase): 310 Hz (310) | Spool Rated Stroke: ±0.75 mm | Mass: 5.2 kg | Mounting Bolts: M8×65L ×4 (30.8–37.7 N·m); 1006 type M6×60L ×4 (13.0–16.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-03EH-40-E | LSVG-03EH OBE Direct Servo Valve, 40 L/min, input E | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 40 L/min | Input Signal / Spool Monitor: E: Current 4–20 mA (12–20 mA input → PABT flow) | Max Operating Pressure: 35 (31.5 for 1006/M6-bolt type) MPa | Tank Port Pressure: 35 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 260 Hz (240) | Frequency Resp. (−90° phase): 310 Hz (310) | Spool Rated Stroke: ±0.75 mm | Mass: 5.2 kg | Mounting Bolts: M8×65L ×4 (30.8–37.7 N·m); 1006 type M6×60L ×4 (13.0–16.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-03EH-40-F | LSVG-03EH OBE Direct Servo Valve, 40 L/min, input F | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 40 L/min | Input Signal / Spool Monitor: F: Current ±10 mA (+input → PABT flow) | Max Operating Pressure: 35 (31.5 for 1006/M6-bolt type) MPa | Tank Port Pressure: 35 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Step Response (0↔100%): 3 ms (3.5) | Frequency Resp. (−3 dB gain): 260 Hz (240) | Frequency Resp. (−90° phase): 310 Hz (310) | Spool Rated Stroke: ±0.75 mm | Mass: 5.2 kg | Mounting Bolts: M8×65L ×4 (30.8–37.7 N·m); 1006 type M6×60L ×4 (13.0–16.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-03EH-60-A | LSVG-03EH OBE Direct Servo Valve, 60 L/min, input A | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 60 L/min | Input Signal / Spool Monitor: A: Voltage ±10 V (+input → PBAT flow) | Max Operating Pressure: 35 (31.5 for 1006/M6-bolt type) MPa | Tank Port Pressure: 35 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Step Response (0↔100%): 4 ms (4.5) | Frequency Resp. (−3 dB gain): 250 Hz (220) | Frequency Resp. (−90° phase): 260 Hz (220) | Spool Rated Stroke: ±0.75 mm | Mass: 5.2 kg | Mounting Bolts: M8×65L ×4 (30.8–37.7 N·m); 1006 type M6×60L ×4 (13.0–16.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-03EH-60-B | LSVG-03EH OBE Direct Servo Valve, 60 L/min, input B | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 60 L/min | Input Signal / Spool Monitor: B: Current 4–20 mA (12–20 mA input → PBAT flow) | Max Operating Pressure: 35 (31.5 for 1006/M6-bolt type) MPa | Tank Port Pressure: 35 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Step Response (0↔100%): 4 ms (4.5) | Frequency Resp. (−3 dB gain): 250 Hz (220) | Frequency Resp. (−90° phase): 260 Hz (220) | Spool Rated Stroke: ±0.75 mm | Mass: 5.2 kg | Mounting Bolts: M8×65L ×4 (30.8–37.7 N·m); 1006 type M6×60L ×4 (13.0–16.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-03EH-60-C | LSVG-03EH OBE Direct Servo Valve, 60 L/min, input C | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 60 L/min | Input Signal / Spool Monitor: C: Current ±10 mA (+input → PBAT flow) | Max Operating Pressure: 35 (31.5 for 1006/M6-bolt type) MPa | Tank Port Pressure: 35 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Step Response (0↔100%): 4 ms (4.5) | Frequency Resp. (−3 dB gain): 250 Hz (220) | Frequency Resp. (−90° phase): 260 Hz (220) | Spool Rated Stroke: ±0.75 mm | Mass: 5.2 kg | Mounting Bolts: M8×65L ×4 (30.8–37.7 N·m); 1006 type M6×60L ×4 (13.0–16.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-03EH-60-D | LSVG-03EH OBE Direct Servo Valve, 60 L/min, input D | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 60 L/min | Input Signal / Spool Monitor: D: Voltage ±10 V (+input → PABT flow) | Max Operating Pressure: 35 (31.5 for 1006/M6-bolt type) MPa | Tank Port Pressure: 35 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Step Response (0↔100%): 4 ms (4.5) | Frequency Resp. (−3 dB gain): 250 Hz (220) | Frequency Resp. (−90° phase): 260 Hz (220) | Spool Rated Stroke: ±0.75 mm | Mass: 5.2 kg | Mounting Bolts: M8×65L ×4 (30.8–37.7 N·m); 1006 type M6×60L ×4 (13.0–16.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-03EH-60-E | LSVG-03EH OBE Direct Servo Valve, 60 L/min, input E | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 60 L/min | Input Signal / Spool Monitor: E: Current 4–20 mA (12–20 mA input → PABT flow) | Max Operating Pressure: 35 (31.5 for 1006/M6-bolt type) MPa | Tank Port Pressure: 35 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Step Response (0↔100%): 4 ms (4.5) | Frequency Resp. (−3 dB gain): 250 Hz (220) | Frequency Resp. (−90° phase): 260 Hz (220) | Spool Rated Stroke: ±0.75 mm | Mass: 5.2 kg | Mounting Bolts: M8×65L ×4 (30.8–37.7 N·m); 1006 type M6×60L ×4 (13.0–16.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 | |
| LSVG-03EH-60-F | LSVG-03EH OBE Direct Servo Valve, 60 L/min, input F | YUKEN | Type: Direct (single-stage), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 60 L/min | Input Signal / Spool Monitor: F: Current ±10 mA (+input → PABT flow) | Max Operating Pressure: 35 (31.5 for 1006/M6-bolt type) MPa | Tank Port Pressure: 35 (7) MPa | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Step Response (0↔100%): 4 ms (4.5) | Frequency Resp. (−3 dB gain): 250 Hz (220) | Frequency Resp. (−90° phase): 260 Hz (220) | Spool Rated Stroke: ±0.75 mm | Mass: 5.2 kg | Mounting Bolts: M8×65L ×4 (30.8–37.7 N·m); 1006 type M6×60L ×4 (13.0–16.0 N·m) | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple), ≥100 VA | Safety Device (select): A=PABT-open / B=PBAT-open / C=neutral | Drain Port Y (select): Std=Y-port (dry, 0.05 MPa max) / W=no Y-port (wet; not for water-glycol) | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Linear Motor: 1.5 A (3.2 A max), coil 7 Ω | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals) | Source: Yuken Cat. I-Edit0, I-22/I-23 |
![[YUKEN] — LSVHG-03EH-210 Two-Stage OBE Linear Servo Valve (210 L/min)](https://img.prosourcemro.com/2026/05/002-153-300x250.png)
On-board electronic (OBE) two-stage linear servo valve, based on the two-stage high-speed linear servo valve with a miniaturized pilot stage and a compact integrated dedicated amplifier, realizing 'high precision, simple, convenient'. Rated flow 210 L/min. Hysteresis 0.1% or less. DC 24 V supply with command-signal input only; built-in fault-diagnosis indicator. Dry and wet pilot types selectable. Usable to NAS 1638 class 10 (ISO4406 21/19/15). Input-signal versions ±10 V / 4–20 mA / ±10 mA with spool monitor.
On-board electronic (OBE) two-stage linear servo valve, based on the two-stage high-speed linear servo valve with a miniaturized pilot stage and a compact integrated dedicated amplifier, realizing 'high precision, simple, convenient'. Rated flow 210 L/min. Hysteresis 0.1% or less. DC 24 V supply with command-signal input only; built-in fault-diagnosis indicator. Dry and wet pilot types selectable. Usable to NAS 1638 class 10 (ISO4406 21/19/15). Input-signal versions ±10 V / 4–20 mA / ±10 mA with spool monitor.
| Product Code | Description | Brand | Spec | |
|---|---|---|---|---|
| LSVHG-03EH-210-4J-A | LSVHG-03EH-210 2-Stage OBE Servo Valve, spool 4J, input A | YUKEN | Type: Two-stage (pilot-operated), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 210 L/min | Spool Type: 4J (A,B,T connected, neutral; +100% input: A/B/C→P→A, D/E/F→P→B) | Input Signal / Spool Monitor: A: Voltage ±10 V (+input → PBAT flow) | Safety Device (per spool): input A/B/C → A (PABT full-open); input D/E/F → blank (PBAT full-open) or EC (solenoid, neutral) | Max Operating Pressure: 31.5 MPa | Tank Port Pressure: 21 MPa | Pilot Supply Pressure: 1.5–21 MPa | Pilot Flow: ≥9 (8) L/min | Drain Port DR Back Pressure: 0.05 MPa max (W type: no DR port, wet) | 4J Characteristic: see characteristic curves (I-44/46/48) | Main Spool Rated Stroke: ±3.5 mm | Main Spool Pressure Area: 3 cm² | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple) | Linear Motor: 2.1 A max, coil 9.6 Ω | Pilot / Drain Form: Internal pilot+ext drain (std) / E=ext pilot / T=int drain | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Mass: 8.5 [11] kg ([ ] = with safety solenoid valve) | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals); W type not for water-glycol | Source: Yuken Cat. I-Edit0, I-31/I-32/I-33 | |
| LSVHG-03EH-210-4J-B | LSVHG-03EH-210 2-Stage OBE Servo Valve, spool 4J, input B | YUKEN | Type: Two-stage (pilot-operated), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 210 L/min | Spool Type: 4J (A,B,T connected, neutral; +100% input: A/B/C→P→A, D/E/F→P→B) | Input Signal / Spool Monitor: B: Current 4–20 mA (12–20 mA → PBAT flow) | Safety Device (per spool): input A/B/C → A (PABT full-open); input D/E/F → blank (PBAT full-open) or EC (solenoid, neutral) | Max Operating Pressure: 31.5 MPa | Tank Port Pressure: 21 MPa | Pilot Supply Pressure: 1.5–21 MPa | Pilot Flow: ≥9 (8) L/min | Drain Port DR Back Pressure: 0.05 MPa max (W type: no DR port, wet) | 4J Characteristic: see characteristic curves (I-44/46/48) | Main Spool Rated Stroke: ±3.5 mm | Main Spool Pressure Area: 3 cm² | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple) | Linear Motor: 2.1 A max, coil 9.6 Ω | Pilot / Drain Form: Internal pilot+ext drain (std) / E=ext pilot / T=int drain | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Mass: 8.5 [11] kg ([ ] = with safety solenoid valve) | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals); W type not for water-glycol | Source: Yuken Cat. I-Edit0, I-31/I-32/I-33 | |
| LSVHG-03EH-210-4J-C | LSVHG-03EH-210 2-Stage OBE Servo Valve, spool 4J, input C | YUKEN | Type: Two-stage (pilot-operated), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 210 L/min | Spool Type: 4J (A,B,T connected, neutral; +100% input: A/B/C→P→A, D/E/F→P→B) | Input Signal / Spool Monitor: C: Current ±10 mA (+input → PBAT flow) | Safety Device (per spool): input A/B/C → A (PABT full-open); input D/E/F → blank (PBAT full-open) or EC (solenoid, neutral) | Max Operating Pressure: 31.5 MPa | Tank Port Pressure: 21 MPa | Pilot Supply Pressure: 1.5–21 MPa | Pilot Flow: ≥9 (8) L/min | Drain Port DR Back Pressure: 0.05 MPa max (W type: no DR port, wet) | 4J Characteristic: see characteristic curves (I-44/46/48) | Main Spool Rated Stroke: ±3.5 mm | Main Spool Pressure Area: 3 cm² | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple) | Linear Motor: 2.1 A max, coil 9.6 Ω | Pilot / Drain Form: Internal pilot+ext drain (std) / E=ext pilot / T=int drain | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Mass: 8.5 [11] kg ([ ] = with safety solenoid valve) | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals); W type not for water-glycol | Source: Yuken Cat. I-Edit0, I-31/I-32/I-33 | |
| LSVHG-03EH-210-4J-D | LSVHG-03EH-210 2-Stage OBE Servo Valve, spool 4J, input D | YUKEN | Type: Two-stage (pilot-operated), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 210 L/min | Spool Type: 4J (A,B,T connected, neutral; +100% input: A/B/C→P→A, D/E/F→P→B) | Input Signal / Spool Monitor: D: Voltage ±10 V (+input → PABT flow) | Safety Device (per spool): input A/B/C → A (PABT full-open); input D/E/F → blank (PBAT full-open) or EC (solenoid, neutral) | Max Operating Pressure: 31.5 MPa | Tank Port Pressure: 21 MPa | Pilot Supply Pressure: 1.5–21 MPa | Pilot Flow: ≥9 (8) L/min | Drain Port DR Back Pressure: 0.05 MPa max (W type: no DR port, wet) | 4J Characteristic: see characteristic curves (I-44/46/48) | Main Spool Rated Stroke: ±3.5 mm | Main Spool Pressure Area: 3 cm² | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple) | Linear Motor: 2.1 A max, coil 9.6 Ω | Pilot / Drain Form: Internal pilot+ext drain (std) / E=ext pilot / T=int drain | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Mass: 8.5 [11] kg ([ ] = with safety solenoid valve) | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals); W type not for water-glycol | Source: Yuken Cat. I-Edit0, I-31/I-32/I-33 | |
| LSVHG-03EH-210-4J-E | LSVHG-03EH-210 2-Stage OBE Servo Valve, spool 4J, input E | YUKEN | Type: Two-stage (pilot-operated), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 210 L/min | Spool Type: 4J (A,B,T connected, neutral; +100% input: A/B/C→P→A, D/E/F→P→B) | Input Signal / Spool Monitor: E: Current 4–20 mA (12–20 mA → PABT flow) | Safety Device (per spool): input A/B/C → A (PABT full-open); input D/E/F → blank (PBAT full-open) or EC (solenoid, neutral) | Max Operating Pressure: 31.5 MPa | Tank Port Pressure: 21 MPa | Pilot Supply Pressure: 1.5–21 MPa | Pilot Flow: ≥9 (8) L/min | Drain Port DR Back Pressure: 0.05 MPa max (W type: no DR port, wet) | 4J Characteristic: see characteristic curves (I-44/46/48) | Main Spool Rated Stroke: ±3.5 mm | Main Spool Pressure Area: 3 cm² | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple) | Linear Motor: 2.1 A max, coil 9.6 Ω | Pilot / Drain Form: Internal pilot+ext drain (std) / E=ext pilot / T=int drain | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Mass: 8.5 [11] kg ([ ] = with safety solenoid valve) | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals); W type not for water-glycol | Source: Yuken Cat. I-Edit0, I-31/I-32/I-33 | |
| LSVHG-03EH-210-4J-F | LSVHG-03EH-210 2-Stage OBE Servo Valve, spool 4J, input F | YUKEN | Type: Two-stage (pilot-operated), on-board electronic (OBE) amp-mounted | Valve Frame: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 210 L/min | Spool Type: 4J (A,B,T connected, neutral; +100% input: A/B/C→P→A, D/E/F→P→B) | Input Signal / Spool Monitor: F: Current ±10 mA (+input → PABT flow) | Safety Device (per spool): input A/B/C → A (PABT full-open); input D/E/F → blank (PBAT full-open) or EC (solenoid, neutral) | Max Operating Pressure: 31.5 MPa | Tank Port Pressure: 21 MPa | Pilot Supply Pressure: 1.5–21 MPa | Pilot Flow: ≥9 (8) L/min | Drain Port DR Back Pressure: 0.05 MPa max (W type: no DR port, wet) | 4J Characteristic: see characteristic curves (I-44/46/48) | Main Spool Rated Stroke: ±3.5 mm | Main Spool Pressure Area: 3 cm² | Built-in Amplifier: On-board (OBE), DC 24 V (DC 21.6–26.4 V incl. ripple) | Linear Motor: 2.1 A max, coil 9.6 Ω | Pilot / Drain Form: Internal pilot+ext drain (std) / E=ext pilot / T=int drain | Connector (select): 1=6+PE / 2=11+PE (Enable, valve-ready, alarm output) | Hysteresis: 0.1% max | Protection: IP65 | Ambient Temp: 0 to +50 °C | Mass: 8.5 [11] kg ([ ] = with safety solenoid valve) | Fluid: Mineral oil (std) / Phosphate-ester (F prefix, fluoro seals); W type not for water-glycol | Source: Yuken Cat. I-Edit0, I-31/I-32/I-33 |
